Neumann TLM 103 25 Years Edition ไมโครโฟนคอนเดนเซอร์

คลิ๊กที่ภาพเพื่อขยาย

ราคา : (กรุณาสอบถาม)

รุ่น :  TLM 103 25 Years Edition
การชำระเงิน : จ่ายหน้าร้าน 11 สาขา / โอนเงิน / เก็บปลายทาง / บัตรเครดิต /ผ่อนชำระ 0% (บางรายการ) / Shopee / Lazada

ลูกค้าองค์กร/ใบเสนอราคา
E-mail
: musicarmsproject@gmail.com

สั่งซื้อ Neumann TLM 103 25 Years Edition ไมโครโฟนคอนเดนเซอร์ผ่านline สั่งซื้อ Neumann TLM 103 25 Years Edition ไมโครโฟนคอนเดนเซอร์ผ่าน messenger

Description

A MODERN CLASSIC
The TLM 103 has quickly become one of the biggest successes in Neumann’s history. Its pristine, clear sound is a modern update on the classic U 87. The TLM 103 is a transformerless cardioid condenser microphone with a gentle presence boost for a stunningly direct sound with breathtaking definition and ultra low noise.

The large diaphragm condenser capsule is derived from the classic K67/87 capsule of the legendary Neumann U 87. However, the TLM 103 has a slightly more modern voicing with a wide presence boost for frequencies above 5 kHz. Its very direct yet refined sound is perfect for vocals and solo instruments that pop out of the mix without effort. Of course, the TLM 103 also has the famous authoritative midrange that has become the hallmark of Neumann microphones and made them the number one choice in studios around the world. A unique feature of the TLM 103 is its impressively deep yet controlled low end, perfect for sonorous voices and powerful bass instruments.

TECHNICAL EXCELLENCE
The TLM 103 has set new standards for technical performance, too. With an incredibly low self-noise of only 7 dB-A , it is among the quietest microphones available. And its high sensitivity of 23 mV/Pa, ensures ultra low noise even with budget preamps and audio interfaces or vintage tube equipment. At the same time, the TLM 103 can handle enormous sound pressure levels of up to 138 dB without the need for preattenuation. Its vast dynamic range of 131 dB makes the TLM 103 a very easy to use studio microphone as it will capture anything from a soft whisper to a thunderous bass drum without adding noise or distortion.

As a member of Neumann’s TLM series, the TLM 103 works with a transformerless output stage, which minimizes transmission losses and ensures a very immediate, uncolored sound, true to the original, as well as a clear, powerful bass response, even at highest signal levels.

APPLICATIONS
The TLM 103 was primarily designed for project studios and broadcast use, but due to its outstanding performance was soon embraced by renowned studios as a more modern sounding alternative to the U87 e.g. for speech, vocals, drums, guitar amps, and piano. The TLM 103 is also often used as a spot mic in classical recordings e.g. for cello and double bass.

Large diaphragm capsule derived from the classic U 87 microphone
Balanced sound with enhanced presence
Cardioid pattern
Extremely low self-noise

Specification

Acoustical operating principle Pressure gradient transducer
Directional Pattern Cardioid
Frequency Range 20 Hz … 20 kHz
Sensitivity at 1 kHz into 1 kohm 23 mV/Pa = –32.5 dBV ± 1 dB
Rated Impedance 50 ohms
Rated load impedance 1 kohms
Equivalent noise level, CCIR¹⁾ 17.5 dB
Equivalent noise level, A-weighted¹⁾ 7 dB-A
Maximum SPL for THD 0.5%²⁾ 138 dB
Signal-to-noise ratio, CCIR (re. 94 dB SPL)¹⁾ 76.5 dB
Signal-to-noise ratio, A-weighted (re. 94 dB SPL)¹⁾ 87 dB
Maximum output voltage 13 dBu
Supply voltage (P48, IEC 61938) 48 V ± 4 V
Current consumption (P48, IEC 61938) 3 mA
Matching connector XLR 3 F
Weight approx. 450 g
Diameter 60 mm
Length 132 mm

ข้อมูล

ตำนานยุคใหม่ที่ยืนหยัด

TLM 103 ได้กลายเป็นหนึ่งในความสำเร็จที่ยิ่งใหญ่ที่สุดในประวัติศาสตร์ของ Neumann อย่างรวดเร็ว ด้วยคุณภาพเสียงที่ใสบริสุทธิ์และชัดเจน เป็นการถ่ายทอดเสียงแบบทันสมัยจากต้นแบบอันเป็นที่รักอย่าง U 87 โดยตรง TLM 103 เป็นไมโครโฟนคอนเดนเซอร์แบบคาร์ดิออยด์ที่ไม่ใช้ทรานส์ฟอร์เมอร์ พร้อมการขับเน้นความชัดในย่านความถี่สูงอย่างนุ่มนวล มอบเสียงที่ตรงประเด็น คมชัด และมีความเงียบเป็นพิเศษ

แคปซูลไดอะแฟรมขนาดใหญ่ของ TLM 103 ได้รับการถ่ายทอดเทคโนโลยีจาก K67/87 ซึ่งเป็นหัวใจของไมโครโฟน U 87 อันโด่งดัง แม้จะยึดพื้นฐานจากแคปซูลแบบคลาสสิก แต่ TLM 103 ได้รับการปรับเสียงให้ทันสมัยยิ่งขึ้น โดยเพิ่มความโดดเด่นในย่านความถี่เหนือ 5 กิโลเฮิรตซ์ ให้เสียงที่ตรงและละเอียด เหมาะสำหรับเสียงร้องและเครื่องดนตรีเดี่ยวที่ต้องการให้ลอยขึ้นมาเหนือมิกซ์โดยไม่ต้องพึ่งการแต่งเสียงเพิ่มเติม พร้อมกับเสียงย่านกลางที่แน่น มั่นคง ซึ่งถือเป็นเอกลักษณ์เฉพาะของ Neumann และเป็นเหตุผลที่ทำให้ไมโครโฟนของแบรนด์นี้ได้รับความไว้วางใจจากห้องอัดทั่วโลก นอกจากนี้ยังมีเสียงย่านต่ำที่ลึกแต่ควบคุมได้ดี เหมาะอย่างยิ่งกับเสียงที่ทุ้มกังวานและเครื่องดนตรีเบสที่มีพลัง

ความเหนือชั้นทางเทคนิค

TLM 103 ได้ยกระดับมาตรฐานด้านประสิทธิภาพทางเทคนิค ด้วยค่าความไวต่อเสียงรบกวนที่ต่ำเพียง 7 dB-A ถือเป็นหนึ่งในไมโครโฟนที่เงียบที่สุดในตลาด และด้วยความไว 23 mV/Pa จึงให้สัญญาณเสียงที่ชัดเจนแม้ใช้ร่วมกับพรีแอมป์ราคาประหยัด อินเทอร์เฟซทั่วไป หรืออุปกรณ์หลอดสุญญากาศรุ่นเก่า พร้อมรองรับระดับความดังเสียงสูงสุดได้ถึง 138 dB โดยไม่จำเป็นต้องใช้แผ่นลดระดับเสียง ไดนามิกเรนจ์ที่กว้างถึง 131 dB ทำให้สามารถบันทึกเสียงได้ตั้งแต่กระซิบเบาๆ จนถึงเสียงกลองกระเดื่องที่ดังสนั่น โดยไม่มีเสียงรบกวนหรือความเพี้ยนของเสียง

ในฐานะสมาชิกของซีรีส์ TLM ไมโครโฟนรุ่นนี้ใช้วงจรขาออกแบบไม่ใช้ทรานส์ฟอร์เมอร์ ลดการสูญเสียของสัญญาณ ถ่ายทอดเสียงได้อย่างตรงไปตรงมาไม่ผิดเพี้ยนจากต้นฉบับ และยังคงให้เสียงเบสที่ชัดเจนทรงพลัง แม้ในระดับสัญญาณสูงสุด

การใช้งาน

แม้จะออกแบบมาเพื่อใช้งานในสตูดิโอโปรเจกต์และงานกระจายเสียงเป็นหลัก แต่ TLM 103 ก็ได้รับการยอมรับอย่างกว้างขวางในห้องอัดมืออาชีพ ด้วยโทนเสียงที่ทันสมัยกว่า U 87 จึงถูกนำไปใช้กับเสียงพูด เสียงร้อง กลอง ตู้แอมป์กีตาร์ และเปียโนอย่างแพร่หลาย รวมถึงยังนิยมใช้เป็นไมโครโฟนเฉพาะจุดในการบันทึกดนตรีคลาสสิก เช่น เชลโล่ และดับเบิลเบส

คุณสมบัติเด่น

  • แคปซูลไดอะแฟรมขนาดใหญ่จากไมโครโฟนรุ่น U 87

  • เสียงสมดุล พร้อมการขับเน้นความชัดในย่านความถี่สูง

  • รูปแบบการรับเสียงแบบคาร์ดิออยด์

  • ค่าความไวต่อเสียงรบกวนต่ำเป็นพิเศษ

สเปค

Acoustical operating principle Pressure gradient transducer
Directional Pattern Cardioid
Frequency Range 20 Hz … 20 kHz
Sensitivity at 1 kHz into 1 kohm 23 mV/Pa = –32.5 dBV ± 1 dB
Rated Impedance 50 ohms
Rated load impedance 1 kohms
Equivalent noise level, CCIR¹⁾ 17.5 dB
Equivalent noise level, A-weighted¹⁾ 7 dB-A
Maximum SPL for THD 0.5%²⁾ 138 dB
Signal-to-noise ratio, CCIR (re. 94 dB SPL)¹⁾ 76.5 dB
Signal-to-noise ratio, A-weighted (re. 94 dB SPL)¹⁾ 87 dB
Maximum output voltage 13 dBu
Supply voltage (P48, IEC 61938) 48 V ± 4 V
Current consumption (P48, IEC 61938) 3 mA
Matching connector XLR 3 F
Weight approx. 450 g
Diameter 60 mm
Length 132 mm
