BOSS SL-2 Slicer: Features and Specifications Overview
The BOSS SL-2 Slicer is a compact guitar effects pedal that evolves from the legacy SL-20 Slicer. It’s designed to “slice” your audio signal into intricate rhythmic patterns, creating compelling sonic grooves with unique characteristics and a variety of internal effects.

Key Features:
* Slicing Effect: Chops your sound into distinct percussive patterns, perfect for creating rhythmic textures.
* 88 Onboard Patterns: Comes with 88 pre-loaded patterns (eight types with 11 variations each) for immediate inspiration.
* Dual Slicer Paths: Capable of processing sound with single or dual slicer paths.
* Internal Effects: Patterns can be processed with multiple internal effects, including filters and pitch shifters (Harmonic mode).
* Control Knobs:
* TYPE & VARIATION: Selects the pattern type and its variations.
* ATTACK & DUTY: Controls the wave shape and length of the sliced audio, allowing for subtle to aggressive slicing.
* TEMPO: Adjusts the tempo of the pattern, with tap tempo capability via the onboard footswitch.
* BALANCE: Adjusts the overall effect level within a +/-12 dB range, balancing the wet/dry signal.
* Stereo I/O: Supports both mono and stereo input and output for versatile integration into any setup.
* Seven Stereo Output Modes: Offers diverse stereo sound experiences, including:
* Fixed
* EFX/Direct
* Random
* Ping-Pong
* Auto
* 3D Cross
* 3D Rotation (creates a sense of spatial movement)
* External Control Options:
* CTL/EXP Jack: Connect up to two footswitches (FS-5U, FS-6, FS-7) or an expression pedal (EV-30, FV-500L/H, Roland EV-5) for real-time parameter control (e.g., tempo, expression, bypass).
* MIDI IN (TRS miniature phone type): Allows for clock sync with drum machines, DAWs, or other MIDI devices, and MIDI CC control.
* USB Connectivity: Connects to the BOSS Tone Studio app (macOS/Windows) via USB to explore and load hundreds of additional patterns.
* Buffered Bypass: Maintains signal integrity when the effect is bypassed.
* Compact Pedal Format: Housed in a standard BOSS compact pedal chassis, making it pedalboard-friendly.

* Sampling Rate: 48 kHz
* AD Conversion: 24 bits + AF method (Adaptive Focus method)
* DA Conversion: 32 bits
* Patterns: 88 (onboard)
* Nominal Input Level: -20 dBu
* Input Impedance: 1 MΩ
* Nominal Output Level: -20 dBu
* Output Impedance: 1 kΩ
* Power Supply: 9V Alkaline battery (approx. 2.5 hours continuous use) or AC adaptor (PSA series, sold separately)
* Current Draw: 95 mA
* Dimensions (W x D x H): 73 x 129 x 59 mm (2-7/8 x 5-1/8 x 2-3/8 inches)
* Weight (including battery): 450 g (1 lb)

* อัตราการสุ่มตัวอย่าง (Sampling Rate): 48 kHz
* การแปลง AD: 24 บิต + AF method (Adaptive Focus method)
* การแปลง DA: 32 บิต
* แพทเทิร์น: 88 รูปแบบ (ในตัวเครื่อง)
* ระดับอินพุตปกติ: -20 dBu
* อิมพีแดนซ์อินพุต: 1 MΩ
* ระดับเอาต์พุตปกติ: -20 dBu
* อิมพีแดนซ์เอาต์พุต: 1 kΩ
* แหล่งจ่ายไฟ: แบตเตอรี่อัลคาไลน์ 9V (ใช้งานได้ต่อเนื่องประมาณ 2.5 ชั่วโมง) หรืออะแดปเตอร์ AC (รุ่น PSA series, จำหน่ายแยกต่างหาก)
* กระแสไฟฟ้าที่ใช้ (Current Draw): 95 mA
* ขนาด (กว้าง x ลึก x สูง): 73 x 129 x 59 มม. (2-7/8 x 5-1/8 x 2-3/8 นิ้ว)
* น้ำหนัก (รวมแบตเตอรี่): 450 กรัม (1 ปอนด์)
