DigiCo Quantum852 ดิจิตอลมิกเซอร์
Description
DigiCo Quantum852: Flagship Digital Mixer for Concerts and Stadium Events
The DiGiCo Quantum852 is the ultimate UK-made digital mixer, revolutionizing the industry with its 7th-generation Super FPGA engine, offering maximum speed and stability. It handles large-scale operations with up to 384 inputs and expands to 192 Aux/Subgroup Busses at 48/96kHz audio resolution.
Featuring three high-brightness 21.3-inch touchscreens and 52 touch-sensitive faders, it combines legendary sound-shaping tools like Mustard Processing and Spice Rack with the new Ultimate Stadius 32-bit preamps, delivering unparalleled clarity and transparency. Perfect for tours, festivals, and stadium events requiring top-tier performance.
Key Features
- 7th-Generation Super FPGA: High-speed, ultra-stable processing power
- Up to 384 Inputs: Handles large and complex audio setups
- 192 Aux/Sub-Group Busses: Includes Master LR/LCR/5.1
- Ultimate Stadius 32-bit Preamps: Clean, transparent, and highly dynamic sound
- Mustard Processing 128 Channels: Emulates classic Tube, Amp, and EQ tones
- Spice Rack 64 Slots: Built-in plugin effects for maximum flexibility
- Nodal Processing 384 Points: Independent EQ/Compression on every Aux Send
- Three 21.3-inch Touchscreens: Plus three 6.8-inch control screens
- 52 Touch-Sensitive Faders: 100mm for precise control
- MADI Ports & DMI Slots: 6 MADI ports, 2 DMI slots supporting Dante, Waves, etc.
- Eco-Friendly Design: Lightweight alloy chassis, excellent cooling, energy-efficient
Who is the Quantum852 For?
- Professional Sound Engineers: Require a stable mixer capable of handling large-scale setups
- Concert Tours and Festivals: Deliver high-quality sound with detailed control
- Stadium-Level Events: Supports complex audio systems in challenging environments
Conclusion
Combining the latest Super FPGA engine, Ultimate Stadius 32-bit preamps, and legendary sound-shaping features, the DiGiCo Quantum852 is a flagship digital mixer delivering unparalleled sound quality and performance, perfect for any major event demanding professional-grade results.
Specification
Audio Console Specifications |
|
|---|---|
| Processing Technology | 7th Generation Super FPGA |
| Sample Rate | 48kHz / 96kHz |
| Latency | < 2ms (Typical) |
| Input Channels | 384 Channels |
| Aux / Sub-Group Busses | 192 Busses |
| Master Busses | LR / LCR / LCRS / 5.1 Master Bus |
| Matrix | 64 x 64 Matrix |
| Control Groups | 36 |
| Mustard Processing | 128 Processing Strips |
| Spice Rack | 64 Plugin Slots |
| Nodal Processing | 384 Instances |
| Dynamic EQ / Multiband Comp | On all Inputs and Outputs |
| Main Screens | 3 x 21.3″ Daylight Viewable Touchscreens |
| Secondary Screens | 3 x 6.8″ TFT LCDs (Bank/Overview) |
| Faders | 52 x 100mm Touch-Sensitive Motorized Faders |
| Mic/Line Inputs | 8 x “Ultimate Stadius” 32-bit Mic Pre-Amps |
| Line Outputs | 8 x “Ultimate Stadius” 32-bit DAC |
| AES/EBU I/O | 4 Inputs / 4 Outputs (Mono Stream) |
| MADI Interface | 6 x MADI Ports (BNC) @ 48k/96k |
| Optocore | Dual Loop (Standard) |
| DMI Slots | 2 x DMI Slots (Up to 64 I/O per slot) |
| USB Interface | 1 x UB MADI (48 in / 48 out Recording) |
| Dimensions (W x D x H) | 1,767mm x 1,075mm x 607mm |
| Weight | 120 kg (264.5 lbs) |
| Power Supply | Redundant PSUs (Hot-swappable) |
ข้อมูลสินค้า
DigiCo Quantum852: มิกเซอร์ดิจิตอลเรือธงสำหรับงานคอนเสิร์ตและอีเว้นท์ระดับสเตเดียม
DiGiCo Quantum852 คือที่สุดแห่งดิจิตอลมิกเซอร์สัญชาติอังกฤษ (UK) ที่ปฏิวัติวงการด้วยขุมพลัง Super FPGA รุ่นที่ 7 มอบความเร็วและความเสถียรสูงสุด รองรับสเกลงานใหญ่ด้วย 384 อินพุต และขยายขีดจำกัดเป็น 192 Aux/Subgroup Busses พร้อมความละเอียดเสียง 48/96kHz
โดดเด่นด้วยหน้าจอสัมผัสความสว่างสูง 21.3 นิ้ว จำนวน 3 จอ พร้อมเฟดเดอร์ 52 ก้าน ผสานฟีเจอร์แต่งเสียงระดับตำนานอย่าง Mustard Processing และ Spice Rack กับปรีแอมป์รุ่น Ultimate Stadius 32-bit ให้คุณภาพเสียงโปร่งใสและดีที่สุดเท่าที่เคยมีมา เหมาะสำหรับงานทัวร์คอนเสิร์ต เฟสติวัล และอีเว้นท์ระดับสเตเดียมที่ต้องการประสิทธิภาพสูงสุด
คุณสมบัติเด่น
- Super FPGA รุ่นที่ 7: ขับเคลื่อนด้วยชิปขั้นสูง ให้ความเร็วและเสถียรภาพสูงสุด
- รองรับอินพุตสูงสุด 384 ช่อง: สำหรับสเกลงานใหญ่และการมิกซ์ที่ซับซ้อน
- Aux/Sub-Group Busses สูงสุด 192 ช่อง: พร้อม Master LR/LCR/5.1
- ปรีแอมป์ Ultimate Stadius 32-bit: ให้เสียงสะอาด โปร่งใส และไดนามิกสูงสุด
- Mustard Processing 128 ช่อง: จำลองโทน Tube, Amp และ EQ คลาสสิก
- Spice Rack 64 สล็อต: เอฟเฟกต์ Plugin ในตัวครบครัน
- Nodal Processing 384 จุด: EQ/Comp อิสระในทุก Aux Send
- จอสัมผัสขนาด 21.3 นิ้ว จำนวน 3 จอ: และจอ 6.8 นิ้ว จำนวน 3 จอ
- เฟดเดอร์ Touch-Sensitive 52 ตัว: ความยาว 100mm สำหรับการควบคุมแม่นยำ
- MADI Ports และ DMI Slots: MADI 6 พอร์ต, DMI 2 ช่อง รองรับ Dante, Waves และอื่น ๆ
- ดีไซน์เป็นมิตรต่อสิ่งแวดล้อม: วัสดุอัลลอยน้ำหนักเบา ระบายความร้อนดีเยี่ยม ประหยัดพลังงาน
เหมาะกับใคร?
- วิศวกรเสียงมืออาชีพ: ต้องการมิกเซอร์ที่เสถียรและรองรับสเกลงานใหญ่
- งานทัวร์คอนเสิร์ตและเฟสติวัล: ให้เสียงคุณภาพสูงและปรับแต่งได้อย่างละเอียด
- อีเว้นท์ระดับสเตเดียม: รองรับระบบเสียงซับซ้อนและสภาพแวดล้อมที่ท้าทาย
สรุป
ด้วยขุมพลัง Super FPGA รุ่นล่าสุด, ปรีแอมป์ Ultimate Stadius 32-bit และฟีเจอร์แต่งเสียงระดับตำนาน DiGiCo Quantum852 คือมิกเซอร์ดิจิตอลเรือธงที่ให้คุณภาพเสียงและประสิทธิภาพเหนือระดับ เหมาะสำหรับทุกงานใหญ่ที่ต้องการผลลัพธ์ระดับมืออาชีพ
รายละเอียดคุณสมบัติ
สเปคเครื่องมิกเซอร์ |
|
|---|---|
| เทคโนโลยีการประมวลผล | 7th Generation Super FPGA |
| อัตราตัวอย่าง (Sample Rate) | 48kHz / 96kHz |
| ความหน่วง (Latency) | < 2ms (โดยทั่วไป) |
| จำนวนช่องสัญญาณเข้า (Input Channels) | 384 ช่อง |
| Aux / Sub-Group Busses | 192 Busses |
| Master Busses | LR / LCR / LCRS / 5.1 Master Bus |
| Matrix | 64 x 64 Matrix |
| Control Groups | 36 |
| Mustard Processing | 128 Processing Strips |
| Spice Rack | 64 Plugin Slots |
| Nodal Processing | 384 Instances |
| Dynamic EQ / Multiband Comp | ใช้ได้กับทุกช่องเข้าและออก |
| หน้าจอหลัก (Main Screens) | 3 x 21.3″ Daylight Viewable Touchscreens |
| หน้าจอรอง (Secondary Screens) | 3 x 6.8″ TFT LCDs (Bank/Overview) |
| เฟดเดอร์ (Faders) | 52 x 100mm Touch-Sensitive Motorized Faders |
| ช่องไมค์/ไลน์เข้า (Mic/Line Inputs) | 8 x “Ultimate Stadius” 32-bit Mic Pre-Amps |
| ช่องสัญญาณออก (Line Outputs) | 8 x “Ultimate Stadius” 32-bit DAC |
| AES/EBU I/O | 4 Inputs / 4 Outputs (Mono Stream) |
| MADI Interface | 6 x MADI Ports (BNC) @ 48k/96k |
| Optocore | Dual Loop (มาตรฐาน) |
| DMI Slots | 2 x DMI Slots (รองรับสูงสุด 64 I/O ต่อสลอต) |
| USB Interface | 1 x UB MADI (48 in / 48 out Recording) |
| ขนาด (กว้าง x ลึก x สูง) | 1,767mm x 1,075mm x 607mm |
| น้ำหนัก | 120 กก. (264.5 ปอนด์) |
| แหล่งจ่ายไฟ | Redundant PSUs (Hot-swappable) |
