Technical Specifications – F40i & F40i Li Smart Amplifier

1. Processing & Effects

• Number of Modules: 9

• Total Effect Models: 109

• Preset Tone Slots: 80

• Impulse Response Format: .wav

• Sampling Rate: 44.1 kHz

• Bit Depth: 32-bit

• Sampling Points: 2048 points

2. Input Interfaces

2.1 Guitar Input

• Interface Type: 1 × 1/4″ unbalanced mono input

• Input Impedance: 1 MΩ

• Maximum Input Level: 10.18 dBu

2.2 Microphone / Instrument Input

• Interface Type: XLR Combo input

• Input Impedance: 15 KΩ / 1 MΩ

• Maximum Input Level: -3.8 dBu / 10.18 dBu

3. Output Interfaces

3.1 Line Output

• Interface Type: 2 × 1/4″ unbalanced mono outputs

• Output Impedance: 600 Ω

• Maximum Output Level: 10.18 dBu

3.2 Headphone Output

• Interface Type: 1 × 1/8″ unbalanced stereo output

• Output Impedance: 4.8 Ω

• Maximum Output Level: 5.141 dBu

3.3 USB

• Interface Type: USB Type-C

• USB Audio: USB 2.0, 2 In / 2 Out, 44.1–192 kHz, 24-bit

General Specifications

• Power Supply:

  • F40i: DC 19V, 3.5A (Center Positive)

  • F40i Li: DC 19V, 3.5A (Center Positive)

• Battery (Li Version):

  • Li-ion, 14.8V, 5200mAh, 76.96Wh

  • Battery Life: Approx. 6 hours (ambient light on, screen brightness 50%, at 25°C)

  • Charging Time: Approx. 2.5 hours (using original adapter)

• Dimensions (L × W × H): 396 × 178 × 179 mm

• Weight:

  • F40i: 3.6 kg

  • F40i Li: 3.95 kg

• Included Accessories:
  Power adapter, USB cable, quick start guide, wrist strap
