NUX NAI – 24 USB Audio Interface

NUX NAI-24 USB Audio Interface: Overview of Features and Specifications
The NUX NAI-24 is a compact and feature-rich USB audio interface designed for home and project studios, offering studio-grade audio quality and versatile functionalities for recording, streaming, and music production.

* 2-in/4-out USB Audio Interface: Provides two inputs and four outputs for flexible connectivity.
* High-Resolution Audio: Supports up to 32-bit/192kHz sample rate for exceptional audio fidelity.
* Class-A Discrete Preamps: Features pure Class A transistor microphone preamps with a maximum gain of 71dB, inspired by classic “76-type” FET compressor circuits, ensuring transparent and high-quality sound capture.
* Built-in Analog Compressor: Includes an easy-to-use analog compressor (76-style FET compressor) with multiple preset modes (Vocal, Guitar/Bass, Live Streaming) for dynamic control directly at the source.
* Professional AD/DA Converters: Equipped with high-quality AKM (Asahi Kasei Microdevices) AD/DA chips for precise sound conversion.
* Studio-Grade Audio Transformers: Features audio transformers on the main outputs (1L/2R) for warm sound characteristics and electrical isolation to prevent ground loop interference.
* Dual Headphone Outputs: Two independently adjustable headphone jacks for flexible monitoring setups.
* Direct Monitoring: Ultra-low latency direct monitoring channels for real-time performance (approx. 3.17 ms at 192 kHz with 32-sample buffer).
* Loopback Function: One-click loopback function, ideal for live streaming and podcasting to capture system audio.
* Switchable Phantom Power: Independent 48V phantom power control per channel for condenser microphones.
* HI-Z Input: Dedicated HI-Z input on Channel 1 for direct connection of guitars and basses.
* USB Bus-Powered: Powered directly via USB-C, eliminating the need for an external power supply.
* Included Software: Comes with a licensed professional recording software: CUBASE 13 LE.

Specifications :
* Connectivity: USB-C (bus-powered)
* Inputs: 2 x Combo XLR/TRS (Mic/Line), 1 x HI-Z (on Channel 1)
* Outputs: 2 x Main Outputs (1L/2R, Balanced TRS), 2 x Auxiliary Outputs (3L/4R, Balanced TRS), 2 x Headphone Outputs
* Max Resolution: 32-bit/192kHz
* Microphone Preamp Gain: Up to 71dB
* Dynamic Range (Mic/Line): ~114dB (A-weighted)
* Dynamic Range (Main Output): ~112dB
* EIN (Equivalent Input Noise): -126dB (A-weighted)
* Dimensions: 194 × 128 × 67 mm
* Weight: 722 g

* การเชื่อมต่อ: USB-C (จ่ายไฟผ่านบัส)
* อินพุต: 2 x Combo XLR/TRS (ไมโครโฟน/ไลน์), 1 x HI-Z (บนช่อง 1)
* เอาต์พุต: 2 x เอาต์พุตหลัก (1L/2R, Balanced TRS), 2 x เอาต์พุตเสริม (3L/4R, Balanced TRS), 2 x เอาต์พุตหูฟัง
* ความละเอียดสูงสุด: 32-bit/192kHz
* เกนปรีแอมป์ไมโครโฟน: สูงสุด 71dB
* ช่วงไดนามิก (ไมโครโฟน/ไลน์): ~114dB (A-weighted)
* ช่วงไดนามิก (เอาต์พุตหลัก): ~112dB
* EIN (Equivalent Input Noise): -126dB (A-weighted)
* ขนาด: 194 × 128 × 67 มม.
* น้ำหนัก: 722 กรัม
