Ortega Acoustic Amplification Series CONE ASH 100W แอมป์กีต้าร์โปร่ง

The Ortega is a 100-watt amplifier head designed for acoustic instruments and vocals, crafted for guitarists and musicians seeking natural sound quality with a unique style.

Its most distinctive feature is the built-in 4-inch speaker, which features a cone made from ash wood, delivering a warm and highly responsive tone. It is perfect for personal practice on its own or can be connected to a speaker cabinet for live performances.

Usage

• For Practice: The H ONE can be used as a standalone unit without needing an external cabinet. The built-in “Ash Wood Cone” speaker provides more than enough clarity for bedroom or studio practice sessions.
• For Live Performance: Connect the H ONE to a speaker cabinet (like the Ortega S ONE or S TWO) to unleash its full 100 watts of power, making it suitable for small to medium-sized venues such as coffee shops, pubs, or acoustic stages.
• For Vocals and Instruments: The second channel features a combo XLR/Line jack, allowing a microphone to be connected for vocals or another instrument simultaneously with a guitar.

Key Features

• Ash Wood Cone Speaker: A unique, built-in 4-inch speaker with an ash wood cone that provides a remarkably warm, smooth, and natural sound.
• 100 Watts Power Output: Delivers loud and clear sound projection suitable for a wide range of applications.
• Two Independent Channels:
  • Channel 1 (Instrument): Designed for acoustic guitars, featuring a 3-band EQ (Bass, Middle, Treble) and a “Color” switch for sound enhancement.
  • Channel 2 (Mic/Instrument): Features a combo XLR/Line input with 48V phantom power for condenser microphones and a 2-band EQ (Bass, Treble).
• Onboard Effects: Built-in Reverb and Chorus effects, with independent level controls for each channel.
• Comprehensive Connectivity:
  • Effect Loop (Send/Return): For integrating external effects pedals.
  • Aux In: For connecting external audio devices like a smartphone to play backing tracks.
  • Headphone Out: For silent practice.
  • XLR DI Out: For sending a balanced signal directly to a mixing console.
  • Speaker Out: For connecting to an external speaker cabinet.

• Type: Acoustic Amplifier Head
• Power Output: 100 Watts RMS
• Built-in Speaker: 1x 4-inch with Ash Wood Cone
• Channels: 2 Channels
  • CH1: 1/4″ Jack Input
  • CH2: XLR / 1/4″ Jack Combo Input
• Effects: Digital Reverb, Digital Chorus (independently controllable per channel)
• Phantom Power: +48V (on Channel 2)
• Rear Panel Connections: Speaker Out (for 4-8 Ohm cabinets), FX Loop (Send/Return), Headphone Out, Aux In, DI Out (Balanced XLR)
• Cabinet Material: Birch Plywood
• Dimensions: 305mm (W) x 180mm (H) x 210mm (D) / (12″ x 7.1″ x 8.27″)
• Weight: 5.4 kg (11.9 lbs)

• ประเภท: แอมป์เฮดสำหรับเครื่องดนตรีอะคูสติก (Acoustic Amplifier Head)
• กำลังขับ: 100 Watts RMS
• ลำโพงในตัว: 1x 4 นิ้ว พร้อมกรวยลำโพงไม้แอช (Ash Wood Cone)
• แชนแนล: 2 แชนแนล
  • CH1: 1/4″ Jack Input
  • CH2: XLR / 1/4″ Jack Combo Input
• เอฟเฟกต์: Digital Reverb, Digital Chorus (แยกการควบคุมในแต่ละแชนแนล)
• Phantom Power: +48V (สำหรับ Channel 2)
• ช่องต่อด้านหลัง: Speaker Out (สำหรับตู้ 4-8 โอห์ม), FX Loop (Send/Return), Headphone Out, Aux In, DI Out (Balanced XLR)
• วัสดุตัวเครื่อง: ไม้เบิร์ช (Birch Plywood)
• ขนาด: 305 มม. (กว้าง) x 180 มม. (สูง) x 210 มม. (ลึก)
• น้ำหนัก: 5.4 กก
