Powersoft Quattrocanali 8804 DSP+D เพาเวอร์แอมป์ 4 แชนแนล
ราคา : 251,200 บาท
Description
Powersoft Quattrocanali 8804 DSP+D: 4-Channel Amplifier with DSP and Dante for Large-Scale Installations
The Powersoft Quattrocanali 8804 DSP+D is a professional 4-channel power amplifier designed for installed sound systems. It supports both low-impedance (Lo-Z) and 70V/100V distributed systems in a single unit, making it ideal for hotels, conference facilities, commercial buildings, and large-scale audio installations requiring high flexibility and reliability.
This model integrates DSP and Dante networking, allowing full control, monitoring, and configuration via ArmoníaPlus and WebApp. It also features SRM (Smart Rail Management) technology to improve efficiency, reduce power consumption, and minimize heat, all within a compact 1RU rack design.
Key Features
- Professional Installation Ready: Designed for medium to large systems
- Lo-Z and 70V/100V Support: Flexible system compatibility
- Built-in DSP: Advanced audio processing
- Dante Networking: Seamless network audio integration
- Software Control: Managed via ArmoníaPlus and WebApp
DSP Features
- Parametric EQ
- Delay up to 100 ms (time alignment)
- Limiter
- Advanced signal processing
Protection Systems
- Clip limiter
- Short circuit protection
- Thermal protection
- DC protection
Ideal Applications
- Hotels and multi-zone systems
- Large conference rooms
- Commercial buildings and malls
- Networked audio systems
Specifications Overview
- 4 Channels
- Supports 2Ω and 70V/100V
- Built-in DSP and Dante
- Delay up to 100 ms
- 1RU rack size
Conclusion
The Powersoft Quattrocanali 8804 DSP+D is a high-end installation amplifier combining DSP and Dante networking in a compact form. It is an ideal solution for large-scale systems requiring reliability, flexibility, and centralized control.
Specification
[Product Name] Details |
|
|---|---|
| Type | Power Amplifier |
| Number of Channels | 4 Channels |
| Output Power @ 2 Ohm | 1800 W x 4 |
| Output Power @ 4 Ohm | 2400 W x 4 |
| Output Power @ 8 Ohm | 1600 W x 4 |
| Bridge Power @ 4 Ohm | 3600 W |
| Bridge Power @ 8 Ohm | 4800 W |
| Max Unclipped Output Voltage | 175 Vpeak |
| Max Output Current | 55 Apeak |
| Power Supply | Universal SMPS with PFC |
| Nominal Voltage | 100-240 V ±10%, 50-60 Hz |
| Operating Temperature | 0° – 45°C |
ข้อมูลสินค้า
Powersoft Quattrocanali 8804 DSP+D: เพาเวอร์แอมป์ 4 แชนแนล พร้อม DSP และ Dante สำหรับงานระบบขนาดใหญ่
Powersoft Quattrocanali 8804 DSP+D เป็นเพาเวอร์แอมป์ 4 แชนแนล สำหรับงานติดตั้งระบบเสียงระดับมืออาชีพ ที่ออกแบบมาเพื่อรองรับทั้งระบบ Low Impedance (Lo-Z) และระบบโวลต์ไลน์ 70V/100V ภายในเครื่องเดียว เหมาะสำหรับงานระบบเสียงในอาคาร โรงแรม ห้องประชุม และพื้นที่เชิงพาณิชย์ที่ต้องการความเสถียรและความยืดหยุ่นสูง
รุ่นนี้มาพร้อม DSP และ Dante ในตัว ช่วยให้สามารถควบคุม ปรับแต่ง และมอนิเตอร์ระบบเสียงผ่าน ArmoníaPlus และ WebApp ได้อย่างสะดวก พร้อมเทคโนโลยี SRM (Smart Rail Management) ที่ช่วยเพิ่มประสิทธิภาพ ลดการใช้พลังงาน และลดความร้อน ทำให้สามารถติดตั้งใน Rack ขนาด 1RU ได้อย่างมั่นใจ
คุณสมบัติเด่น
- รองรับงานติดตั้งระดับมืออาชีพ: เหมาะกับระบบเสียงขนาดกลางถึงใหญ่
- รองรับ Lo-Z และ 70V/100V: ใช้งานได้หลากหลายในเครื่องเดียว
- DSP ในตัว: รองรับการปรับแต่งเสียงแบบละเอียด
- Dante Networking: รองรับระบบเสียงผ่านเครือข่าย
- ควบคุมผ่าน Software: ใช้งานผ่าน ArmoníaPlus และ WebApp
ฟังก์ชัน DSP
- Parametric EQ
- Delay สูงสุด 100 ms (Time Alignment)
- Limiter
- ระบบจัดการสัญญาณเสียงขั้นสูง
ระบบป้องกัน
- Clip Limiter
- Short Circuit Protection
- Thermal Protection
- DC Protection
เหมาะกับงานประเภท
- โรงแรม / ระบบเสียงหลายโซน
- ห้องประชุมขนาดใหญ่
- อาคารสำนักงาน / ศูนย์การค้า
- ระบบเสียงเชิงพาณิชย์ (Network Audio)
สเปคโดยสรุป
- 4 แชนแนล
- รองรับ 2Ω และ 70V/100V
- มี DSP และ Dante ในตัว
- รองรับ Delay สูงสุด 100 ms
- ขนาด 1RU
สรุป
Powersoft Quattrocanali 8804 DSP+D เป็นเพาเวอร์แอมป์ระดับสูงสำหรับงานติดตั้ง ที่รวม DSP และ Dante ไว้ในเครื่องเดียว เหมาะสำหรับระบบเสียงขนาดใหญ่ที่ต้องการความเสถียร การควบคุมผ่านเครือข่าย และประสิทธิภาพสูงสุดในพื้นที่จำกัด
รายละเอียดคุณสมบัติ
[ชื่อสินค้า] รายละเอียด |
|
|---|---|
| ประเภท | เพาเวอร์แอมป์ |
| จำนวนแชนแนล | 4 แชนแนล |
| กำลังขับที่ 2 โอห์ม | 1800 วัตต์ x 4 |
| กำลังขับที่ 4 โอห์ม | 2400 วัตต์ x 4 |
| กำลังขับที่ 8 โอห์ม | 1600 วัตต์ x 4 |
| กำลังขับแบบบริดจ์ 4 โอห์ม | 3600 วัตต์ |
| กำลังขับแบบบริดจ์ 8 โอห์ม | 4800 วัตต์ |
| แรงดันเอาต์พุตสูงสุด | 175 Vpeak |
| กระแสเอาต์พุตสูงสุด | 55 Apeak |
| ภาคจ่ายไฟ | Switch Mode Power Supply พร้อม PFC |
| แรงดันไฟฟ้า (Nominal) | 100-240V ±10%, 50-60 Hz |
| อุณหภูมิการทำงาน | 0° – 45°C |
