Powersoft Unica 4K8: 8-Channel 4000W Network Power Amplifier with Integrated DSP

The Powersoft Unica 4K8 is a professional installation power amplifier featuring 8 output channels and delivering up to 4000 watts of total power in a compact 1U rack unit. It is designed for medium to large installed sound systems such as theatres, auditoriums, churches, hotels, conference centers, and commercial buildings.

The amplifier supports both low-impedance (Lo-Z) loudspeakers and 70/100V line systems on the same output channel without manual switching, providing exceptional flexibility for installed audio systems. It also supports Audio over IP networking including Dante and AES67.

Equipped with Power Sharing technology and Smart Rails Management (SRM), the Unica 4K8 dynamically distributes power across channels for maximum efficiency. The amplifier can be fully configured through ArmoníaPlus software, while remote monitoring and firmware updates can be managed through the MyUniverso cloud platform.

Key Features

• 8-Channel Power Amplifier with 4000W Total Output: Each channel provides approximately 500W depending on load, all within a compact 1U chassis.
• Bridge Mode Capability: Channels can be bridged to deliver up to 1000W for higher power requirements.
• Power Sharing Technology: Output channels can borrow power from other channels under asymmetric load conditions for optimal efficiency.
• Smart Rails Management (SRM): Automatically adjusts internal voltage rails to reduce energy loss and improve overall efficiency.
• Lo-Z and 70/100V Compatibility: Both impedance types are supported on the same output channel without manual switching.
• Advanced Network Audio Support: Compatible with Dante and AES67 audio networking with support for daisy-chain and redundant Dante topologies.
• Remote Monitoring via MyUniverso: Allows remote system monitoring, configuration, and firmware updates.
• PoE / PoE++ Support: Keeps amplifier logic operational even if the main AC power is temporarily interrupted.
• Easy Configuration Backup: System configurations can be saved to a USB drive and restored quickly when replacing hardware.
• Dolby Atmos Connect Support: Compatible with immersive audio systems and dynamic music distribution applications.

Who is the Powersoft Unica 4K8 For?

• Installed Audio Systems: Ideal for hotels, shopping malls, corporate buildings, and public venues.
• Theatres and Auditoriums: Suitable for venues requiring high performance amplification with DSP control.
• Public Address and Background Music Systems: Perfect for distributed audio and building-wide BGM applications.
• System Integrators and Audio Engineers: Designed for professionals who require flexible power distribution and network-based system control.

Conclusion

The Powersoft Unica 4K8 combines high power density, intelligent power management, and advanced network audio integration in a compact 1U amplifier. With support for both Lo-Z and 70/100V systems, cloud-based monitoring, and flexible DSP control, it is a powerful and efficient solution for modern installed sound applications.
