Quest HPi111 Compact Passive Speaker 10″ ลำโพง Passive

คลิ๊กที่ภาพเพื่อขยาย
ยี่ห้อ : Quest

ราคา : 43,520 บาท

54,400 บาท ประหยัด20%
รุ่น :  Quest HPi111 ตู้ลำโพง Passive Speaker
🚚 การจัดส่ง

ซื้อครบ 500 บาท จัดส่งฟรีทั่วประเทศ

🚀 จัดส่งด่วนภายในวัน ทั่วกทม. และปริมณฑล

💳 ช่องทางการชำระเงิน
จ่ายหน้าร้าน 13 สาขา โอนเงิน เก็บปลายทาง บัตรเครดิต ผ่อน 0% (บางรายการ) Shopee Lazada

🏢
ลูกค้าองค์กร / ขอใบเสนอราคา
สั่งซื้อ Quest HPi111 Compact Passive Speaker 10″ ลำโพง Passiveผ่านline สั่งซื้อ Quest HPi111 Compact Passive Speaker 10″ ลำโพง Passiveผ่าน messenger

Description

Quest HPi111: Compact Loudspeaker System

The QUEST HPi 111 is a medium to high powered 90 degree dispersion compact speaker system designed to project voice and music throughout mid sized performance venues. It can be hung in small arrays or function as a stand alone speaker system in mobile PA production with or without sub bass enhancement. Contained within the discrete HPI111 appearance there are a number of key technical innovations to improve performance in real venue environments.

Key Features

  • Dispersion: 90 degree
  • Venue Size: Mid-sized
  • Application: Voice and music projection
  • Mounting: Hang in small arrays or standalone
  • HF Driver: 1″ 90 degree asymmetrical wave guide (rotatable)
  • LF Driver: 10″ high powered woofer
  • Ideal for: Performing arts centres, houses of worship, corporate theatres, etc.
  • Installation System: Multi-purpose light weight QR flying/installation system
  • Acoustics: Extends the “critical distance” by directing sound away from reflective surfaces
  • Vocal Clarity: Exceptional with precise dispersion control

Conclusion

The Quest HPi111 is a versatile and powerful compact loudspeaker system suitable for a wide range of applications in mid-sized venues. Its rotatable high-frequency waveguide and ability to extend the critical distance make it particularly effective in environments where vocal intelligibility is crucial. Whether used in arrays or as a standalone system, the HPi111 delivers high-definition audio performance.

Specification

Quest HPi111 Details

Rec Amplifier 480 – 720W
Nom. Impedance 8 ohm
Frequency Response 70Hz – 19kHz
Sensitivity 96 dB
Max SPL 129dB
Directivity Rotatable Asymmetric [100 degrees horizontal; 60 degrees vertical +15/-45deg]
Woofer 10″ Ferrite Woofer
Tweeter 1” Ferrite Compression Driver
Connections & Wiring 2x Speakon 1+/-
Dimensions 641.5 x 306 x 352mm
Weight 17.4kg net

ข้อมูลสินค้า

Quest HPi111: ลำโพง Compact อเนกประสงค์

QUEST HPi 111 เป็นระบบลำโพงขนาดกลางถึงกำลังขับสูงที่มีมุมกระจายเสียง 90 องศา ออกแบบมาเพื่อฉายเสียงพูดและดนตรีทั่วสถานที่แสดงขนาดกลาง สามารถแขวนเป็นแถวขนาดเล็ก หรือใช้งานเป็นระบบลำโพงเดี่ยวในการผลิต PA แบบเคลื่อนที่ โดยมีหรือไม่มีการเสริมเสียงเบสซับ ภายในรูปลักษณ์ที่ไม่โดดเด่นของ HPI111 มีนวัตกรรมทางเทคนิคที่สำคัญหลายประการเพื่อปรับปรุงประสิทธิภาพในสภาพแวดล้อมของสถานที่จริง

คุณสมบัติเด่น

  • ระบบลำโพง: Compact พร้อมมุมกระจายเสียง 90 องศา
  • เหมาะสำหรับ: สถานที่แสดงขนาดกลาง
  • การใช้งาน: ฉายเสียงพูดและดนตรี
  • การติดตั้ง: แขวนเป็นแถวเล็กๆ หรือใช้เดี่ยวๆ ได้
  • HF: Wave guide แบบอะซิมเมตริกัล 1 นิ้ว หมุนได้
  • LF: วูฟเฟอร์กำลังขับสูง 10 นิ้ว
  • เหมาะสำหรับ: ศูนย์ศิลปะการแสดง, ศาสนสถาน, โรงละครองค์กร และอื่นๆ
  • ระบบติดตั้ง: QR flying/installation system อเนกประสงค์
  • ระยะวิกฤต: ขยาย “critical distance” โดยการนำเสียงออกจากผนังและเพดาน
  • ความคมชัด: ให้เสียงร้องที่คมชัดเป็นพิเศษ และควบคุมพื้นที่การกระจายเสียงได้ดี

สรุป

Quest HPi111 เป็นระบบลำโพง compact ที่มีความสามารถรอบด้าน เหมาะสำหรับสถานที่ขนาดกลาง ให้เสียงพูดและดนตรีที่ชัดเจน สามารถติดตั้งได้หลากหลายรูปแบบ ทั้งแขวนและตั้งพื้น ด้วยคุณสมบัติของ HF wave guide ที่ออกแบบมาเป็นพิเศษ ทำให้สามารถใช้งานได้ดีแม้ในสภาพแวดล้อมที่มีการสะท้อนเสียงมาก ทำให้เป็นตัวเลือกที่ยอดเยี่ยมสำหรับหลากหลายการใช้งานที่ต้องการคุณภาพเสียงที่ดี

รายละเอียดคุณสมบัติ

รายละเอียด Quest HPi111

แอมพลิฟายเออร์ที่แนะนำ 480 – 720W
ความต้านทานปกติ 8 โอห์ม
การตอบสนองความถี่ 70Hz – 19kHz
ความไว 96 dB
ระดับความดันเสียงสูงสุด 129dB
การกระจายเสียง หมุนได้แบบอสมมาตร [แนวนอน 100 องศา; แนวตั้ง 60 องศา +15/-45 องศา]
วูฟเฟอร์ วูฟเฟอร์เฟอร์ไรท์ 10 นิ้ว
ทวีตเตอร์ ไดรเวอร์บีบอัดเฟอร์ไรท์ 1 นิ้ว
การเชื่อมต่อและสายไฟ 2x Speakon 1+/-
ขนาด 641.5 x 306 x 352 มม.
น้ำหนัก 17.4 กก. สุทธิ
