กีตาร์ไฟฟ้า ESP E-II Horizon-III FM ( Made in Japan )

History and overview of ESP E-II Horizon-III FM (Made in Japan)

• ESP E-II Series is a group of high-quality guitars produced at ESP’s factory in Tokyo, Japan, which is operated by the same team of craftsmen as the famous original ESP Standard model.

• Horizon-III is a new design from the original Horizon shape. With a body design with 2 buttons, the neck looks hovering (extended beveled upper horn and shortened lower horn) for beauty, balance and more convenient high line access.

• The Horizon-III FM (Flamed Maple top) model uses a Neck-Thru-Body structure to help sustain long and clear sound. Meet the needs of high-quality play.

ESP E-II Horizon-III FM – Specifications (English)

🔹 Construction
• Neck-Thru-Body → Provides long sustain and high stability

🔹 Body
• Alder body
• Flamed Maple top (showcasing beautiful wood grain)

🔹 Neck
• 3-Piece Maple neck
• Neck shape: Thin U
• Inlays: Pearloid Offset Block Inlays

🔹 Fingerboard
• Ebony fingerboard
• Scale length: 25.5” (648 mm)
• Fingerboard radius: 305 mm (12”)
• Frets: 24 Extra Jumbo Frets

🔹 Hardware
• Bridge: Gotoh TOM Bridge & String-Thru-Body
• Tuners: Gotoh Locking Tuners
• Nut: Bone Nut (42 mm)
• Hardware color: Black Nickel

🔹 Electronics
• Pickups:
• Neck: Seymour Duncan SH-2 Jazz
• Bridge: Seymour Duncan TB-14 Custom 5
• Controls:
• 1 × Volume
• 1 × Tone (Push/Pull Coil-Split)
• 3-Way Toggle Switch

🔹 Finish
• Available finishes: See Thru Black Cherry Sunburst (STBCSB), Reindeer Blue (RDB)
• Gloss finish

🔹 Strings
• Elixir Nanoweb / Cleartone (.010–.046)

🔹 Accessories
• ESP Form-Fit Hardshell Case included
• Made in Japan (ESP Tokyo Factory)

ESP E-II Horizon-III FM – Specs

🔹 Construction (โครงสร้าง)
• Neck-Thru-Body → ให้ sustain ยาวนานและความเสถียรสูง

🔹 Body (บอดี้)
• ไม้ Alder
• ท็อปไม้ Flamed Maple (โชว์ลายไม้สวยงาม)

🔹 Neck (คอ)
• ไม้ 3-Piece Maple
• ทรงคอ: Thin U
• อินเลย์: Pearloid Offset Block Inlays

🔹 Fingerboard (ฟิงเกอร์บอร์ด)
• ไม้ Ebony
• สเกล: 25.5” (648 มม.)
• รัศมีฟิงเกอร์บอร์ด: 305 มม. (12”)
• จำนวนเฟรต: 24 Extra Jumbo Frets

🔹 Hardware (ฮาร์ดแวร์)
• สะพานสาย: Gotoh TOM Bridge & String-Thru-Body
• ลูกบิด: Gotoh Locking Tuners
• Nut: Bone Nut (42 มม.)
• สีฮาร์ดแวร์: Black Nickel

🔹 Electronics (อิเล็กทรอนิกส์)
• ปิ๊กอัพ:
• คอ: Seymour Duncan SH-2 Jazz
• บริดจ์: Seymour Duncan TB-14 Custom 5
• คอนโทรล:
• 1 Volume
• 1 Tone (Push/Pull Coil-Split)
• 3-Way Toggle Switch

🔹 Finish (ฟินิช)
• ฟินิช: See Thru Black Cherry Sunburst (STBCSB), Reindeer Blue (RDB)
• เคลือบเงาแบบ Gloss Finish

🔹 Strings (สาย)
• Elixir Nanoweb / Cleartone (.010–.046)

🔹 Accessories (อุปกรณ์เสริม)
• ESP Form-Fit Hardshell Case
• ผลิตใน: Japan (ESP Tokyo Factory)
