Prism Sound Lyra2

คลิ๊กที่ภาพเพื่อขยาย
ยี่ห้อ : Prism Sound

ราคา : 90,000 บาท

100,000 บาท ประหยัด10%
รุ่น :  Prism Sound Lyra2 ออดิโอ อินเตอร์เฟส Audio Interface
🚚 การจัดส่ง

ซื้อครบ 500 บาท จัดส่งฟรีทั่วประเทศ

🚀 จัดส่งด่วนภายในวัน ทั่วกทม. และปริมณฑล

💳 ช่องทางการชำระเงิน
จ่ายหน้าร้าน 13 สาขา โอนเงิน เก็บปลายทาง บัตรเครดิต ผ่อน 0% (บางรายการ) Shopee Lazada

🏢
ลูกค้าองค์กร / ขอใบเสนอราคา
สั่งซื้อ Prism Sound Lyra2ผ่านline สั่งซื้อ Prism Sound Lyra2ผ่าน messenger

วีดีโอ


YouTube video

Description

Prism Sound Lyra 2 2 x 4 USB Audio Interface

2-in/4-out USB Audio Interface with Reference-Grade AD/DA Converters, 2 Mic/Line/Instrument Preamps, ADAT I/O, S/PIDF I/O, and 1 Headphone Output
Prism Sounds’ Lyra 2 combines ultra-stable clocking, reference-grade AD/DA conversion, and two world-class microphone preamplifiers to deliver a sonically superior compact USB audio interface. For small project studios or traveling producers who are uncompromising when it comes to fidelity, the Prism Sound Lyra 2 is an ideal choice, with just the right amount of control and connectivity for vocal sessions and overdubs. An intuitive software control panel offers access to advanced features, including M/S functions, soft clipping, and adding additional channels via optical input. Highly regarded by discerning engineers at Sweetwater, Prism Sound has a matchless reputation for providing pristine digital audio. For unmatched audio quality in a compact format, you just can’t beat the Lyra 2 USB audio interface from Prism Sound.



Prism Sound Lyra 2 2 x 4 USB Audio Interface Features:

  • USB interface and AD/DA converter with industry-leading clocking and conversion
  • Reference-grade clocking for ultra-low jitter and maximum digital accuracy
  • 2 pristine mic/line/instrument preamps
  • 4 analog line outputs and headphone out
  • ADAT I/O supports up to 8 additional channels
  • S/PDIF input and output can be used for AES3 signals with included adapter cables
  • Lyra Controller applet for Mac and PC provides comprehensive input/output control, signal routing, foldback mixing, and more
  • Overkiller soft limiter available on all analog inputs to protect against digital clipping
  • Verifile technology allows you to monitor signals or analyze audio files for data corruption

Specification

Technical Specifications

🎛️ Type USB Audio Interface
💻 Computer Connectivity USB 2.0
🧱 Form Factor Rackmount
🔁 Simultaneous I/O 2 × 4
🎙️ Preamps 2 × Mic / Line / Instrument
Phantom Power Yes
📶 A/D Resolution Up to 24-bit / 96kHz
🎸 Analog Inputs 2 × 1/4″ (Instrument)
2 × 1/4″ (Line)
2 × XLR (Mic)
🔊 Analog Outputs 4 × 1/4″ (Line)
🔌 Digital Inputs 1 × Coaxial (S/PDIF, ADAT)
1 × Optical Toslink (S/PDIF, ADAT)
📤 Digital Outputs 1 × Coaxial (S/PDIF, ADAT)
1 × Optical Toslink (S/PDIF, ADAT)
🎧 Headphone Output 1 × 1/4″
🔗 USB 1 × Type-B
🌐 Data I/O Ethernet
⏱️ Clock I/O 2 × BNC (In / Out)
🧰 Software Control Panel Applet
🍎 macOS Requirements OS X 10.9.5 or later
🪟 Windows Requirements Windows 7 SP1 or later
📏 Rack Size 1U
📐 Dimensions (H × W × D) 3.75″ × 19.01″ × 9.52″
⚖️ Weight 4.62 lbs



ข้อมูลสินค้า

Prism Sound Lyra 2 – 2 x 4 USB Audio Interface

2-in / 4-out USB Audio Interface พร้อม Reference-Grade AD/DA Converters,
ไมค์พรีแอมป์ระดับโลก 2 ช่อง, ADAT I/O, S/PDIF I/O และช่องหูฟัง

Prism Sound Lyra 2 ผสานระบบ Clocking ที่มีความเสถียรสูงเป็นพิเศษ
เข้ากับการแปลงสัญญาณ AD/DA ระดับอ้างอิง (Reference-Grade)
และไมโครโฟนพรีแอมป์คุณภาพระดับโลกจำนวน 2 ช่อง
เพื่อมอบคุณภาพเสียงที่ใส สะอาด และแม่นยำอย่างแท้จริง

เหมาะอย่างยิ่งสำหรับสตูดิโอขนาดเล็ก โปรดิวเซอร์ที่เดินทางบ่อย
หรือผู้ใช้งานที่ไม่ยอมประนีประนอมด้านคุณภาพเสียง
Lyra 2 ให้การควบคุมและการเชื่อมต่อที่ลงตัว
สำหรับงานอัดเสียงร้องและโอเวอร์ดับระดับมืออาชีพ

ซอฟต์แวร์ควบคุม Lyra Controller ใช้งานง่าย
พร้อมฟีเจอร์ขั้นสูง เช่น M/S Processing, Soft Clipping
และการเพิ่มช่องสัญญาณผ่าน Optical Input
ซึ่งสะท้อนถึงชื่อเสียงของ Prism Sound
ในฐานะผู้นำด้านระบบดิจิทัลออดิโอระดับสูง

Prism Sound Lyra 2 – Key Features

  • USB Audio Interface และ AD/DA Converter พร้อมระบบ Clocking ชั้นนำของอุตสาหกรรม
  • Reference-Grade Clocking ให้ค่า Jitter ต่ำมาก และความแม่นยำสูงสุด
  • ไมค์ / ไลน์ / อินสตรูเมนต์พรีแอมป์คุณภาพสูง 2 ช่อง
  • เอาต์พุตไลน์อะนาล็อก 4 ช่อง และช่องหูฟังแยกอิสระ
  • ADAT I/O รองรับการเพิ่มอินพุตสูงสุดถึง 8 ช่อง
  • S/PDIF I/O รองรับสัญญาณ AES3 (พร้อมสายแปลงในกล่อง)
  • Lyra Controller สำหรับ Mac และ PC ควบคุม Routing, Foldback Mixing และ I/O ได้ครบถ้วน
  • Overkiller Soft Limiter บนทุกอินพุตอะนาล็อก ป้องกัน Digital Clipping
  • Verifile Technology สำหรับตรวจสอบและวิเคราะห์ความสมบูรณ์ของข้อมูลเสียง

รายละเอียดคุณสมบัติ

ข้อมูลทางเทคนิค (Technical Specifications)

🎛️ ประเภทสินค้า USB Audio Interface
💻 การเชื่อมต่อกับคอมพิวเตอร์ USB 2.0
🧱 รูปแบบตัวเครื่อง Rackmount
🔁 อินพุต / เอาต์พุตพร้อมกัน 2 × 4
🎙️ จำนวนพรีแอมป์ 2 × Mic / Line / Instrument
Phantom Power มี
📶 ความละเอียด A/D สูงสุด 24-bit / 96kHz
🎸 อินพุตอะนาล็อก 2 × 1/4″ (Instrument)
2 × 1/4″ (Line)
2 × XLR (Mic)
🔊 เอาต์พุตอะนาล็อก 4 × 1/4″ (Line)
🔌 อินพุตดิจิทัล 1 × Coaxial (S/PDIF, ADAT)
1 × Optical Toslink (S/PDIF, ADAT)
📤 เอาต์พุตดิจิทัล 1 × Coaxial (S/PDIF, ADAT)
1 × Optical Toslink (S/PDIF, ADAT)
🎧 ช่องหูฟัง 1 × 1/4″
🔗 พอร์ต USB 1 × Type-B
🌐 Data I/O Ethernet
⏱️ Clock I/O 2 × BNC (In / Out)
🧰 ซอฟต์แวร์ Control Panel Applet
🍎 ระบบปฏิบัติการ macOS OS X 10.9.5 หรือใหม่กว่า
🪟 ระบบปฏิบัติการ Windows Windows 7 SP1 หรือใหม่กว่า
📏 ขนาดแร็ค 1U
📐 ขนาดตัวเครื่อง (สูง × กว้าง × ลึก) 3.75″ × 19.01″ × 9.52″
⚖️ น้ำหนัก 4.62 ปอนด์
