Radial Bassbone OD เอฟเฟคเบส

คลิ๊กที่ภาพเพื่อขยาย
ยี่ห้อ : Radial

ราคา : 16,900 บาท

รุ่น :  Radial Bassbone OD เอฟเฟคเบส Bass Effect
🚚 การจัดส่ง

ซื้อครบ 500 บาท จัดส่งฟรีทั่วประเทศ

🚀 จัดส่งด่วนภายในวัน ทั่วกทม. และปริมณฑล

💳 ช่องทางการชำระเงิน
จ่ายหน้าร้าน 13 สาขา โอนเงิน เก็บปลายทาง บัตรเครดิต ผ่อน 0% (บางรายการ) Shopee Lazada

🏢
ลูกค้าองค์กร / ขอใบเสนอราคา
สั่งซื้อ Radial Bassbone OD เอฟเฟคเบสผ่านline สั่งซื้อ Radial Bassbone OD เอฟเฟคเบสผ่าน messenger

วีดีโอ


YouTube video

Description

Radial Bassbone OD: The Bass Preamp & Overdrive

The Radial Bassbone OD is a bass preamp featuring two fully-equipped input channels, each with separate level and EQ controls, and a shared overdrive circuit.

This pedal allows you to connect two bass guitars and sculpt the tone of each one individually. The EQ settings are specifically tailored for bass, including a high-pass filter to roll off excessive low end. Input A features a PZB booster for upright basses with a piezo transducer, while Input B includes a Drag Control impedance correction circuit for a more natural tone with magnetic pickups.

Key Features

  • Dual Independent Channels: Easily toggle between two basses, each with its own level and EQ controls for precise tone-sculpting.
  • High-Quality Overdrive Circuit: A powerful on-board overdrive that can be shared between both channels, adding grit and warmth without sacrificing low-end clarity.
  • Integrated Piezo Preamp: Input A includes a PZB booster to optimize the sound of upright basses equipped with piezo pickups, ensuring a natural tone.
  • Headphone Output for Practice: A dedicated headphone jack allows for silent practice, while the built-in Radial DI provides a balanced output for sending your signal to the PA.

Conclusion

The Radial Bassbone OD is an all-in-one solution for bassists who demand flexibility and exceptional tone. Whether you are switching between basses on stage, fine-tuning your sound, adding grit with overdrive, or managing your signal to the PA, the Bassbone OD handles it all flawlessly. This makes it an essential tool for any bassist seeking professional-grade performance.

Specification

Radial Bassbone OD Specifications

Audio Circuit Type Discrete Class-A FET input with low noise ICs
Frequency Response 20Hz ~ 18kHz
Dynamic Range 85dB
Gain Unity gain device
Clip Level +10dBu at XLR
Total Harmonic Distortion 0.05% @ -15dBu
Intermodulation Distortion 0.2% @ -20dBu
Input Impedance CH-A: 220K/10M | CH-B: Variable from 22K to 1.8M
Output Impedance 300 Ohms at XLR
Equivalent Input Noise -92dBu at XLR
Noise Floor -100dB
Maximum Input +7 dBu
Features 180° polarity reverse, Ground lift, HPF, Drag Control, Level Control, Phase Adjustment, Effects Loop, EQ Control, Boost
Input Connectors 1/4″
Output Connectors 1/4″, XLR, 3.5mm
Construction 14-gauge steel
Size (L x W x D) 8″ x 4.2″ x 2″ (203 x 107 x 48mm)
Weight 2.55 lbs (1157 grams)
Shipping Size (L x W x D) 10.75″ x 5″ x 2.75″ (273 x 127 x 70mm)
Shipping Weight 2.8 lbs (1270 grams)
Power +15VDC/400mA adapter included
Conditions For use in dry locations only between 5°C and 40°C
Warranty Radial 3-year, transferable

ข้อมูลสินค้า

Radial Bassbone OD: ปรีแอมป์เบสพร้อมโอเวอร์ไดรฟ์

Radial Bassbone OD คือปรีแอมป์เบสที่มีสองอินพุตพร้อมคุณสมบัติครบครัน โดยแต่ละแชนเนลมีปุ่มควบคุมระดับเสียงและ EQ แยกกัน พร้อมกับวงจรโอเวอร์ไดรฟ์ที่ใช้ร่วมกัน

Bassbone OD ช่วยให้คุณสามารถเชื่อมต่อเบสสองตัวและปรับแต่งโทนเสียงของแต่ละตัวได้อย่างอิสระ ด้วยการควบคุม EQ ที่ออกแบบมาเพื่อเบสโดยเฉพาะ พร้อมฟิลเตอร์ High-pass เพื่อลดความถี่ต่ำที่เกินจำเป็น นอกจากนี้ อินพุต A ยังมีตัวบูสเตอร์ PZB สำหรับเบส Upright ที่ใช้ปิ๊กอัพ Piezo ในขณะที่อินพุต B มีวงจร Drag Control เพื่อปรับโหลดบนปิ๊กอัพแม่เหล็กให้ได้โทนเสียงที่เป็นธรรมชาติยิ่งขึ้น

คุณสมบัติเด่น

  • สองแชนเนลอิสระ: สลับระหว่างเบสสองตัวได้อย่างง่ายดาย พร้อมการควบคุม EQ และระดับเสียงที่แยกกันสำหรับแต่ละอินพุต
  • วงจรโอเวอร์ไดรฟ์คุณภาพสูง: วงจรไดรฟ์แบบออนบอร์ดที่สามารถใช้ร่วมกันได้ทั้งสองแชนเนล ช่วยเพิ่มความหนาและโทนเสียงที่อบอุ่นให้กับเบสโดยไม่ทำให้ย่านความถี่ต่ำหายไป
  • ปรีแอมป์ Piezo ในตัว: อินพุต A มีบูสเตอร์ PZB สำหรับปรับแต่งเสียงของเบส Upright ที่ใช้ปิ๊กอัพ Piezo ให้มีความเป็นธรรมชาติ
  • เอาต์พุตหูฟัง: ช่วยให้สามารถฝึกซ้อมได้อย่างเงียบเชียบ พร้อมเอาต์พุต DI ของ Radial ในตัวเพื่อส่งสัญญาณไปยัง PA

สรุป

Radial Bassbone OD เป็นอุปกรณ์ที่ครบครันสำหรับนักเบสที่ต้องการความยืดหยุ่นและโทนเสียงที่ยอดเยี่ยมในเครื่องเดียว ไม่ว่าจะเป็นการสลับเบสบนเวที, การปรับแต่งโทนเสียงอย่างละเอียด, การเพิ่มความกรันด้วยโอเวอร์ไดรฟ์ หรือการจัดการสัญญาณไปยัง PA ทั้งหมดนี้ Bassbone OD สามารถทำได้อย่างไร้ที่ติ ทำให้เป็นเครื่องมือที่จำเป็นสำหรับนักเบสทุกคน

รายละเอียดคุณสมบัติ

ข้อมูลจำเพาะ Radial Bassbone OD

ประเภทวงจรเสียง Discrete Class-A FET input with low noise ICs
การตอบสนองความถี่ 20Hz ~ 18kHz
Dynamic Range 85dB
Gain Unity gain device
Clip Level +10dBu (ที่ XLR)
Total Harmonic Distortion 0.05% @ -15dBu
Intermodulation Distortion 0.2% @ -20dBu
Input Impedance CH-A: 220K/10M | CH-B: ปรับค่าได้ตั้งแต่ 22K ถึง 1.8M
Output Impedance 300 โอห์ม (ที่ XLR)
Equivalent Input Noise -92dBu (ที่ XLR)
Noise Floor -100dB
Maximum Input +7 dBu
คุณสมบัติ 180° polarity reverse, Ground lift, HPF, Drag Control, Level Control, Phase Adjustment, Effects Loop, EQ Control, Boost
ขั้วต่ออินพุต 1/4″
ขั้วต่อเอาต์พุต 1/4″, XLR, 3.5mm
โครงสร้าง เหล็กหนา 14-gauge
ขนาด (ย x ก x ส) 8″ x 4.2″ x 2″ (203 x 107 x 48 มม.)
น้ำหนัก 2.55 ปอนด์ (1157 กรัม)
ขนาดจัดส่ง (ย x ก x ส) 10.75″ x 5″ x 2.75″ (273 x 127 x 70 มม.)
น้ำหนักจัดส่ง 2.8 ปอนด์ (1270 กรัม)
การใช้พลังงาน รวมอะแดปเตอร์ +15VDC/400mA
เงื่อนไขการใช้งาน สำหรับใช้ในที่แห้งเท่านั้น ระหว่างอุณหภูมิ 5°C ถึง 40°C
การรับประกัน รับประกันแบบโอนสิทธิ์ได้ 3 ปีของ Radial
