Rupert Neve Designs 5052 Shelford Mic Pre / Inductor EQ (vertical only)

คลิ๊กที่ภาพเพื่อขยาย
ยี่ห้อ : Rupert Neve Designs

ราคา : 99,700 บาท

133,000 บาท ประหยัด25%
รุ่น :  Rupert Neve Designs 5052 Shelford ปรีแอมป์ไมโครโฟน Microphone Preamp
การจัดส่ง : ซื้อครบ 500 บาท จัดส่งฟรีทั่วประเทศ / จัดส่งด่วนภายในวัน ทั่วกทม. และปริมณฑล
การชำระเงิน : จ่ายหน้าร้าน 11 สาขา / โอนเงิน / เก็บปลายทาง / บัตรเครดิต /ผ่อนชำระ 0% (บางรายการ) / Shopee / Lazada

ลูกค้าองค์กร/ใบเสนอราคา
E-mail
: musicarmsproject@gmail.com

สั่งซื้อ Rupert Neve Designs 5052 Shelford Mic Pre / Inductor EQ (vertical only)ผ่านline สั่งซื้อ Rupert Neve Designs 5052 Shelford Mic Pre / Inductor EQ (vertical only)ผ่าน messenger

วีดีโอ


Description

This preamp lives up to its heritage

Just like Rupert Neve’s vintage preamps, the 5052 pre boasts 72dB of discrete, Class A gain coupled with beefy square-core transformers. The sound is pristine – and gloriously massive. The 5052, however, is packing a secret weapon the classics never had: its output transformer features the Silk Red/Blue and Texture controls from the Portico II Series that let you tailor the harmonic content and tonality of the output stage.

By engaging these controls and sufficiently driving your output, you can add delectable 2nd-order harmonic distortion (that’s the good kind), imbuing your tracks with juicy-rich thickness when desired — with no danger of overloading the output stage. The mic pre section also gives you a sweepable 20–250Hz highpass filter, Mic/Line selection, 48V phantom power, and polarity reverse.

Classic Neve EQ with enhanced control

The 5052’s 3-band, custom-tapped inductor EQ was inspired by classic Neve EQ designs. The low frequency band is mostly based on the 1064, famous for its creamy, rich bass. Unlike the 1064 however, the 5052’s LF band may be used in either a peak or shelf mode to give you amazing control over the punch and girth of your low end. The 5052’s inductor midrange band is based on the legendary 1073 equalizer, and is perfect for sweetening vocals and instruments while nudging them forward in your mix.

For those problematic frequencies, the mid band’s proportional-Q response is just what the doctor ordered. The high-frequency band is a hybrid vintage/modern design that blends inductor circuitry from the 1073 with capacitor-based topologies to give you vintage sound with enhanced control. Neve uses low-feedback, Class A gain blocks in each EQ section, and these make a vital contribution to the 5052’s overall sound. And while these design elements are very much “vintage Neve,” the 5052 also leverages contemporary components and techniques that weren’t possible back in the day, giving you the best of old and new.

The magical sound of Neve

Rupert Neve is an audio legend whose electronics designs defined the golden age of analog. Those of us at Sweetwater who have had the privilege of working on a Neve 8078 or its predecessors can attest to the fact that Neve’s Series 80 consoles were indeed the pinnacle of hand-wired analog mixing desks. Mr. Neve has remained at the forefront of audio-circuit innovation for over half a century, and his current company, Rupert Neve Designs, continues to advance the state of the art with cutting-edge products that sound incredible and intelligently address the challenges of the digital age. If you’re not quite sure what the fuss is all about, check out Dave Grohl’s documentary, “Sound City.”

Specification

  • Modern design and components, classic Neve sound
  • The definitive 1073 feature set: mic pre, highpass filter, and 3-band inductor EQ
  • Variable Silk/Texture control; simultaneous pre/post “tape” operation
  • Sweepable 20–250Hz highpass filter, Mic/Line selection, 48V phantom power, and polarity reverse
  • Made to fit Rupert Neve Designs 5088 console or any of three available vertical racks
  • Requires standalone power supply (not included)
  • Handcrafted in the USA

ข้อมูล

Rupert Neve Designs 5052 Shelford Mic Pre / Inductor EQ (vertical only)

ปรีแอมป์นี้คู่ควรกับตำนานของมัน

เช่นเดียวกับปรีแอมป์วินเทจของ Rupert Neve, ปรีแอมป์ 5052 มี เกน Class A ที่ไม่ต่อเนื่อง 72dB จับคู่กับ หม้อแปลงแกนสี่เหลี่ยมขนาดใหญ่ เสียงที่ได้นั้นบริสุทธิ์ และทรงพลังอย่างยิ่ง อย่างไรก็ตาม 5052 มีอาวุธลับที่รุ่นคลาสสิกไม่มี: หม้อแปลงเอาต์พุตมี ปุ่มควบคุม Silk Red/Blue และ Texture จาก Portico II Series ที่ช่วยให้คุณปรับแต่งเนื้อหาฮาร์มอนิกและโทนเสียงของส่วนเอาต์พุตได้

ด้วยการใช้งานปุ่มควบคุมเหล่านี้และขับเอาต์พุตให้เพียงพอ คุณสามารถเพิ่ม ฮาร์มอนิกบิดเบือนลำดับที่ 2 ที่น่ารับประทาน (ซึ่งเป็นชนิดที่ดี) ทำให้แทร็กของคุณมีความหนาแน่นและอิ่มเอมตามต้องการ — โดยไม่ต้องกังวลว่าส่วนเอาต์พุตจะโอเวอร์โหลด ส่วนปรีไมค์ยังให้คุณได้รับ ฟิลเตอร์ Highpass แบบ Sweepable 20–250Hz, ปุ่มเลือก Mic/Line, ไฟ Phantom 48V และปุ่มกลับเฟส


EQ Neve คลาสสิกพร้อมการควบคุมที่ปรับปรุง

EQ แบบ 3 แบนด์ที่ใช้ขดลวดแบบกำหนดเองของ 5052 ได้รับแรงบันดาลใจจากการออกแบบ EQ Neve แบบคลาสสิก แบนด์ความถี่ต่ำส่วนใหญ่จะอ้างอิงจาก 1064 ซึ่งมีชื่อเสียงในด้านเสียงเบสที่นุ่มนวลและหนักแน่น อย่างไรก็ตาม แตกต่างจาก 1064, แบนด์ LF ของ 5052 สามารถใช้ได้ทั้งในโหมด peak หรือ shelf เพื่อให้คุณควบคุมความหนักแน่นและความหนาของเสียงเบสได้อย่างน่าทึ่ง แบนด์เสียงกลางแบบขดลวดของ 5052 อ้างอิงจาก อีควอไลเซอร์ 1073 ในตำนาน และเหมาะอย่างยิ่งสำหรับการปรับเสียงร้องและเครื่องดนตรีให้ไพเราะขึ้นพร้อมทั้งผลักดันให้เด่นชัดในมิกซ์ของคุณ

สำหรับความถี่ที่มีปัญหา การตอบสนอง Q แบบสัดส่วนของแบนด์กลางคือสิ่งที่เหมาะที่สุด แบนด์ความถี่สูงเป็นการออกแบบแบบไฮบริดวินเทจ/สมัยใหม่ที่ผสมผสานวงจรขดลวดจาก 1073 เข้ากับโทโพโลยีแบบตัวเก็บประจุเพื่อให้คุณได้เสียงวินเทจพร้อมการควบคุมที่ปรับปรุง Neve ใช้บล็อกเกน Class A ที่มีฟีดแบ็คน้อยในแต่ละส่วน EQ และสิ่งเหล่านี้มีส่วนสำคัญต่อเสียงโดยรวมของ 5052 และในขณะที่องค์ประกอบการออกแบบเหล่านี้เป็นแบบ “วินเทจ Neve” อย่างแท้จริง 5052 ยังใช้ประโยชน์จากส่วนประกอบและเทคนิคที่ทันสมัยซึ่งเป็นไปไม่ได้ในสมัยก่อน ทำให้คุณได้รับสิ่งที่ดีที่สุดทั้งจากเก่าและใหม่


เสียงอันมหัศจรรย์ของ Neve

Rupert Neve เป็นตำนานในวงการเสียง ผู้ซึ่งการออกแบบวงจรอิเล็กทรอนิกส์ได้กำหนดยุคทองของอนาล็อก พวกเราที่ Sweetwater ที่ได้รับสิทธิพิเศษในการทำงานบน Neve 8078 หรือรุ่นก่อนหน้า สามารถยืนยันได้ว่าคอนโซล Series 80 ของ Neve เป็นจุดสูงสุดของโต๊ะผสมเสียงอนาล็อกที่เดินสายด้วยมือจริงๆ คุณ Neve ยังคงเป็นผู้นำด้านนวัตกรรมวงจรเสียงมานานกว่าครึ่งศตวรรษ และบริษัทปัจจุบันของเขา Rupert Neve Designs ยังคงพัฒนาสถานะของศิลปะด้วยผลิตภัณฑ์ที่ล้ำสมัยที่ให้เสียงที่น่าทึ่งและแก้ไขปัญหาของยุคดิจิทัลได้อย่างชาญฉลาด หากคุณยังไม่แน่ใจว่าเรื่องวุ่นวายทั้งหมดนี้เกี่ยวกับอะไร ลองชมสารคดีของ Dave Grohl เรื่อง “Sound City”

สเปค

  • ดีไซน์ที่ทันสมัยและส่วนประกอบใหม่ล่าสุด ให้เสียง Neve แบบคลาสสิก
  • ชุดคุณสมบัติ 1073 ที่สมบูรณ์แบบ: ปรีแอมป์ไมค์, ฟิลเตอร์ Highpass, และ EQ แบบ 3 แบนด์ที่ใช้ขดลวด
  • ปุ่มควบคุม Variable Silk/Texture; สามารถเลือกใช้งานก่อน/หลัง “เทป” ได้พร้อมกัน
  • ฟิลเตอร์ Highpass แบบ Sweepable ตั้งแต่ 20–250Hz, ปุ่มเลือก Mic/Line, ไฟ Phantom 48V, และปุ่มกลับเฟส
  • ออกแบบมาให้เข้ากับคอนโซล Rupert Neve Designs 5088 หรือแร็คแนวตั้งที่มีอยู่สามแบบ
  • ต้องใช้แหล่งจ่ายไฟแบบ Standalone (ไม่รวมอยู่ในชุด)
  • ผลิตด้วยมือในสหรัฐอเมริกา
