AUDIX F5

f5

AFFORDABLE DYNAMIC INSTRUMENT MICROPHONE

The Fusion Series microphones represent affordable excellence.

The f5 dynamic instrument microphone is an ideal choice for snare, toms, percussion, and acoustic instruments in live and studio applications. A hypercardioid pick-up pattern helps to minimize feedback and isolate the instrument from ambient sound.

The f5’s low impedance and balanced output allow interference-free performance.

Designed, assembled, and tested by Audix in the USA.

Seriously Versatile: Audix f5

Want a mic that you can grab, place on on almost anything (including vocals), and get great results? The Audix f5 is just such a mic. With its low-mass diaphragm, the f5 gives you precise, natural sound. Its 137dB SPL capability and hypercardioid pickup pattern make it a perfect choice for snare drum or toms, capturing the full dynamics with excellent off-axis rejection. The f5 is awesome on percussion instruments, but then again, it excels at anything you throw its way – including guitar and bass cabs, brass, and even acoustic instruments, vocals, and speech!

The f5’s roadworthy build – typical of the Audix Fusion Series – includes a precision cast zinc alloy body, steel mesh grill, and an attractive black coat finish that’ll stand up to life on the road. This Audix f5 is a seriously versatile studio and stage workhorse that belongs in every engineer’s toolkit.

Audix f5 Dynamic Instrument Mic Features at a Glance:

• Great sound, onstage or in the studio
• This versatile mic is perfect for:
• Snare, toms, percussion, guitar and bass cabinets, brass, flute, woodwinds,
• Electric and acoustic instruments, vocals and speech
• Hypercardioid pickup pattern delivers superior isolation
• Low-mass diaphragm gives you precise, natural sound
• Rugged construction; made in the U.S.

• Transducer Type Dynamic
• Frequency Response 55 Hz – 15 kHz
• Polar Pattern Hypercardioid
• Output Impedance 580 ohms
• Sensitivity 2.2 mV / Pa @ 1k
• Capsule Technology LM Type A
• Off-Axis Rejection >20 dB
• Maximum SPL ≥137 dB
• Power Requirements None
• Connector 3-pin XLRm
• Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
• Materials / Finish Zinc Alloy / Black Finish
• Weight 283 g / 10 oz
• Length 145 mm / 5.7 in

รายละเอียด AUDIX F5

• ประเภทตัวแปลงสัญญาณไดนามิก
• การตอบสนองความถี่ 55 Hz – 15 kHz
• รูปแบบโพลาร์ Hypercardioid
• ความต้านทานขาออก 580 โอห์ม
• ความไว 2.2 mV / Pa @ 1k
• เทคโนโลยีแคปซูล LM Type A
• Off-Axis Rejection >20 dB
• SPL สูงสุด≥137 dB
• ขั้วต่อ XLRm 3 ขา
• ขั้วความดันบวกบนไดอะแฟรมสร้างแรงดันไฟฟ้าบวกที่ขา 2 เทียบกับขา 3 ของขั้วต่อ XLR ขาออก
• วัสดุโลหะผสมสังกะสีสีดำ
• น้ำหนัก 283 ก. / 10 ออนซ์
• ความยาว 145 มม. / 5.7 นิ้ว
