iCON iKeyboard 3 Mini

iKeyboard 3 Mini

• Velocity-sensitive piano style keyboard
• Combined pitch/modulation joystick
• Octave up/down buttons
• Transpose up/down buttons
• Sustain button
• Arpeggiator button is equipped to activate Arpeggiator function
• Combined Gate/Arp(type) joystick to adjust arpeggiator different parameters
• Tap button is equipped to use with arpeggiator function
• Multi velocity curves available for selection
• Midi output jack
• Class-compliant with Windows XP, Vista (32-bit), Windows 7 (32-bit & 64-bit),
  Windows 8 (32-bit & 64-bit),Windows 10 (32-bit & 64-bit) and Mac OS X (IntelMac)
• USB bus-powered
• USB 2.0 high speed connectivity
• Supporting most of the DAW including Cubase, Nuendo, Samplitude, Logic Pro, Ableton Live, Pro Tools, Reaper and Reason etc
• iMapTM software included for easy mapping of MIDI functions
• Firmware upgrade available simply via USB connection and iMap software
• Robust metal casing with Kensington lock port

Specification

• To computer USB connector (mini B type)
• To i-series controller USB connector (standard type)
• Power supply USB bus power
• Current consumption 100mA or less
• Weight 0.8kg (1.76lb)
• Dimensions 402.4(L) x 121.3(W) x 41(H)mm
• Dimensions 15.84”(L) x 4.78”(W) x 1.61”(H)
