iCon NeoAmp

NeoAmp

• Four Channel Stereo headphone amplifier
• Maximum Output power on each channel regardless of different headphone impedances
• Four 1/4-inch stereo headphone outputs
•  Individual volume control for each headphone output
•  Stereo 1/4 inch input connector
•  Rugged aluminum extrusion chassis
•  Large rubber bumper feet
•  18 Volt AC adapter included
•  Three year extended warranty

Input

• Input impedance: 100k ohm unbalanced
• Maximum input level: +19 dBV
• Input connectors: Stereo 1/4″ TRS connector

Output

• Output connectors: 4xStereo 1/4″ TRS female connectors
• Output impedance: 100 ohm each output

System

• Max gain: 20 dB/Channel
• S/N Ratio: > 90 dB
• THD: < 0.05%
• IMD (SMPTE): < 0.05%

General

• Power supply: ICON AC18V/700mA power adapter
• Weight: 1.1kg (2.4lbs)
• Dimensions (WxDxH): 200 x 124 x 51 mm
• Dimensions (WxDxH): 7.9″ x 4.9″ x 2.0″
