IFI AUDIO GND Defender

Ground control to Major components.

• The optimum configuration for each system is one Ground/Earth for the whole system. If a system has multiple Grounds/Earths, then it often creates unwanted ground loops. These systems will then have an annoying low-frequency hum (emitted from the speakers).
• Current solutions either jeopardise (i) both safety and EMI shielding (e.g. cheater plug), or (ii) EMI shielding. And most are single country (US) uses only.
• The GND Defender in the correct way, intelligently detects a ground loop and will cut the ground for that component.

AI ground detection.

With a GND Defender at the IEC power input, it will intelligently detect and remove the ground loop at the component.

Behind this, the GND Defender:

• Intelligently breaks DC ground loops to eliminate ground loop hum
• EMI shielding is retained
• Equipment Safety is unaffected (not a ground lift – so maintains equipment safety ground)

If multiple ground loops exist, more than one GND Defender may be required.

The GND Defender is smarter than the average ground lift. By a long way.

Battleship build.

The GND Defender is not only at the cutting-edge in terms of technology but also safety:

• High-performance glass passivated semiconductor
• High Case Dielectric Strength of 1500VRMS UL Listed
• X7R Capacitor
• High-temperature stability
• Flame resistant IEC socket/connector/chassis
• Fireproof polymers UL94-V0

Remember that best practice is to always keep at least one direct power cable connection.

• AI Ground Detection: Each unit will automatically disconnect the ground on that device
• Ground Safe: Auto reinstatement of ground connection to pass current if a fault is detected
• Voltage rating: 90 – 240 volts
• Surge overload rating: 220A
• Continuous current rating: 10A (1100W – 2400W)
• Universal IEC: Hospital-grade IEC connectors
• Dimensions: 68 x 37 x 32 mm / 2.7” x 1.5” x 1.3”
• Weight: 61g / 2.2oz

รายละเอียด IFI AUDIO GND Defender

• AI Ground Detection: แต่ละยูนิตจะตัดการเชื่อมต่อกราวด์บนอุปกรณ์นั้นโดยอัตโนมัติ
• Ground Safe: คืนสถานะการเชื่อมต่อกราวด์โดยอัตโนมัติเพื่อส่งกระแสหากตรวจพบข้อผิดพลาด
• ระดับแรงดันไฟฟ้า: 90 – 240 โวลต์
• พิกัดไฟเกิน: 220A
• พิกัดกระแสไฟต่อเนื่อง: 10A (1100W – 2400W)
• Universal IEC: ขั้วต่อ IEC ระดับโรงพยาบาล
• ขนาด: 68 x 37 x 32 มม.
• น้ำหนัก: 61 กรัม
