JBL CV1570 ตู้ลำโพง Passive 15 นิ้ว 2 ทาง 1400 วัตต์

CV1570: Premium Compact High-Output Full-Range Loudspeaker

The CV1570 is a premium and compact high-output full-range loudspeaker. It features a 380 mm (15 in) humidity protection woofer with an optimal demodulating/cooling aluminum ring inside, ensuring high power, low distortion, and low power compression. It also incorporates a 2414H-C 25 mm (1 in) polymer diaphragm compression driver. The 100° × 70° coverage pattern provides smooth, even coverage whether used in vertical or horizontal orientation. A high-order passive network minimizes band overlap for superior sound.

Key Features

• 15” High Efficiency Woofer Design: Provides powerful and clear low-frequency output.
• 1” Polymer Diaphragm Compression Driver: Delivers crisp and articulate high frequencies.
• Robust Enclosure: Constructed of 15 mm medium density fiberboard with a rugged, durable finish for longevity.
• 100° × 70° Coverage Pattern: Ensures even and smooth sound dispersion both on and off-axis.
• Heavy Duty Steel Grille: Features a powder-coated 1.5mm steel grille with an elegant design for driver protection and a sleek professional appearance.
• Precision Engineered Crossover: Optimizes driver integration for seamless frequency transitions.
• Rotatable JBL COMMERCIAL Logo: Allows for flexible installation in both horizontal and vertical applications.
• Ideal for Limited Ceiling Height Installations: Designed to fit well in venues with height restrictions.
• White Color Available: White (-WH) color option is available upon request to match specific decor.
• Versatile Sound Reinforcement: Perfect for restaurants, canteens or dining halls, cafés, conference rooms, halls, school rooms, etc.
• High-Performance Satellite Speaker: Can be used effectively with subwoofers for a complete sound system.

Conclusion

The CV1570 is a full-range loudspeaker that offers exceptional sound quality and performance in a compact design. With its robust features and flexible installation options, it is an ideal choice for various sound reinforcement applications requiring clarity and high output.
