Mackie Onyx8

คลิ๊กที่ภาพเพื่อขยาย
ยี่ห้อ : Mackie
รุ่น :  Mackie Onyx8 Analog Mixer
การจัดส่ง : ซื้อครบ 500 บาท จัดส่งฟรีทั่วประเทศ / จัดส่งด่วนภายในวัน ทั่วกทม. และปริมณฑล

ราคา : 16,900 บาท

การชำระเงิน : ผ่อนไม่ใช้บัตรเครดิต / จ่ายหน้าร้าน 6สาขา / โอนเงิน / เก็บปลายทาง / บัตรเครดิต /ผ่อนชำระ 0% (บางรายการ) / Shopee / Lazada

สั่งซื้อ Mackie Onyx8ผ่านline สั่งซื้อ Mackie Onyx8ผ่าน messenger

วีดีโอ


YouTube video

Description

Professional-grade Mixer for the Studio and Stage

When it comes to world-class quality and versatility, the Mackie Onyx8 8-channel Analog Mixer with Multi-track USB is the perfect go-to board for all your live sound and recording needs. Compact enough for both home use and the traveling engineer, the Onyx8 combines 24-bit/96kHz multitrack recording with high-gain preamps and a low-noise design to meet the uncompromising demands of professionals everywhere. With its British-style sound, Mackie’s timeless Perkins EQ is a favorite among many Sweetwater engineers, and the studio-grade effects sound stellar when used with any mix. Top it off with a full-color display and easy navigation, and you get a formidable analog mixer capable of capturing audio with impeccable quality.



Award-winning preamps and legendary EQ

Don’t let the Onyx8’s compact design fool you — this analog mixer delivers solid studio-quality sound guaranteed to take your mixes to the next level. Four award-winning mic preamps offer an impressive 60dB of gain, and the top-notch analog circuitry works exceptionally well when aiming for a professional product. Taking inspiration from veteran Mackie engineer Cal Perkins, the Onyx8’s Perkins EQ offers a wider, highly musical Q filter, with a sweepable midrange producing classic sounds reminiscent of the 1960s and ’70s. Plus, this powerful mixer’s digital effects engine offers a wide variety of enhancements, with user-customizable reverbs, delays, and more at your disposal.

User-friendly high-resolution recording

The Onyx8’s USB connectivity makes recording professional-quality mixes easier than ever. Simply plug into your Mac or PC, and you’re ready to tap into high-resolution 24-bit/96kHz multitrack recording. The Onyx8’s full-color display and single-knob interface let you navigate FX parameters, onboard SD recording, and playback, with physical buttons for Previous, Next, Record, and Play/Pause functions.

Geared for the studio, venue, and more

With its compact design and wide versatility, the Onyx8 analog mixer is ready to tackle practically any situation imaginable. Its stellar effects processor can handle everything from massive performances to studio recordings, live streams, and more, with adjustable parameters and a dedicated EQ making it easy to dial in that perfect sound. Bluetooth streaming capabilities allow you to connect your Bluetooth-enabled devices to any of the Onyx8’s channels, with the streamed audio routed to either the Aux Sends or Main Mix.

Mackie Onyx8 8-channel Analog Mixer with Multi-track USB Features:

  • 4 award-winning Onyx mic preamps
  • Analog circuitry delivers premium-quality sound with minimum noise
  • Analog/USB channel strips with flexible routing
  • Studio-grade effects with user customization options
  • 3-band Perkins EQ with On/Off hard bypass switches
  • Switchable hi-Z inputs for guitars, bass, and other instruments
  • 100Hz low-cut filter and 48V phantom power on all mic channels
  • High-resolution 24-bit/96kHz multi-track recording to Mac/PC via USB
  • Full-color display and single-knob interface
  • Dedicated buttons for Previous, Next, Record, and Play/Pause
  • Bluetooth streaming capabilities

Specification

Mixer

  • Number of Analog Input Channels: 8 (2 Mono / 3 Stereo)
  • Number of Mic Preamps: 2
  • Analog Output Channels: 2 x Stereo Master Output, 2 x Stereo Control Room/Monitor Output, 1 x Mono Aux Send Output, 1 x Mono FX Send Output, 1 x Stereo Headphone Output
  • Mix Routing: 1 x Stereo Main Mix per Mono Input Channel, Stereo Input Channel, Aux Bus/Subgroup
  • Faders: None
  • Main Meter: 2 x 12-Segment LED
  • Meter Range: Main Meter:-30 dB to +20 dB Peak/Clip



Signal Processing

  • Gain/Trim Range: 60 dB
  • Input Pad: None
  • Input Polarity: None
  • Dynamic Processing: None
  • Sidechain Filters: None
  • EQ: 3-Band Semi-Parametric (Mono Channels), 3-Band Shelving/Notch/Peak
  • EQ Parameters: Mono Channels: High: ±15 dB at 12 kHz, Mid: ±15 dB at 100 Hz to 5 kHz, Low: ±15 dB at 80 Hz
  • Stereo Channels: High: ±15 dB at 12 kHz, Mid: ±15 dB at 2.5 kHz, Low: ±15 dB at 80 Hz
  • Filters Input Channels: 1 x High-Pass: 100 Hz
  • Solo/Mute: Solo per Input Channel, Mute per Input Channel, Bus, FX Bus, Master
  • Internal Effects: Yes



Digital Audio

  • Sample Rates: 96 kHz
  • Bit Depth: 24-Bit
  • DSP: None
  • Word Clock Input: None



Connectivity

  • Analog Inputs: 2 x Combo XLR-1/4″ TRS Balanced Mic/Line Input, 2 x XLR 3-Pin Balanced Mic Input, 6 x 1/4″ TRS Balanced/Unbalanced Line Input, 2 x 1/4″ TRS Unbalanced Line Insert, 2 x 1/4″ TRS Balanced/Unbalanced Hi-Z Input, 6 x 1/4″ TRS Balanced/Unbalanced Stereo Line Input (3 Stereo Pairs), 1 x 1/4″ TRS Footswitch Input
  • Analog Outputs: 2 x XLR 3-Pin Balanced Stereo Main Output (1 Stereo Pair), 2 x 1/4″ TRS Balanced/Unbalanced Stereo Main Output (1 Stereo Pair), 2 x 1/4″ TRS Balanced/Unbalanced Stereo Control Room Output (1 Stereo Pair), 1 x 1/4″ TRS Balanced/Unbalanced Mono Aux/Monitor Output, 1 x 1/4″ TRS Balanced/Unbalanced FX Send
  • Phantom Power: +48 V (on 4 Channels)
  • USB: 1 x USB Type-B (Audio Playback, Host Connection, Recording)
  • Wireless Connectivity: Bluetooth



Recording

  • Max Multitrack Recording: 8 Tracks
  • Media Support: SD



Compatibility

  • OS Compatibility: None



Power

  • AC Power Connector: 1 x IEC Input
  • Power Consumption: 30 W



Physical

  • Rack Mountable: No
  • Dimensions: 10.5 x 11 x 4.5″ / 26.7 x 27.9 x 11.4 cm
  • Weight: 7 lb / 3.2 kg
  • Warranty: 1-year all inclusive, nontransferable

×
