Moog Subsequent 37 Analog Synthesizer: Even Better Than Before
The Subsequent 37 is a (2-note) paraphonic analog synthesizer that builds on the award-winning design of the Sub 37 Tribute Edition. Its control panel has 40 knobs and 74 switches, placing a vast array of analog sound-design tools and onboard sequencing options immediately at your command. The Subsequent 37 improves upon its source through the implementation of user-requested enhancements. Each enhancement maintains the magic and character of its predecessor while also providing access to new dimensions of sound and improved playability.

Key Features
- Even Better Than Before: Mixer section has double the headroom, providing access to a new range of classic clean tones in both mono and duo performance modes.
- Enhanced Analog Sound: Reshaped gain-staging in the Ladder filter boosts harmonic saturation and analog compression, resulting in an overall richer low end. Retuned Multidrive circuit extends well beyond the grit and growl of the original Sub 37.
- Powerful Sound Shaping: Comes stacked with 256 pre-loaded presets, two variable waveshape oscillators, one square wave sub oscillator, one analog noise generator, an external input/feedback generator, and a 20Hz–20kHz Moog Ladder filter with multiple slopes.
- Flexible Control: Features two assignable mod busses, two DAHDSR looping envelopes, an ultrapowerful arpeggiator/sequencer, and a fully featured mixer section with dedicated controls and mutes for each sound source.
- Excellent Playability: 37-note semi-weighted keybed with velocity sensitivity and aftertouch.
Summary
The Moog Subsequent 37 Analog Synthesizer takes the acclaimed Sub 37 to the next level with enhanced sonic capabilities and improved playability. Offering a rich analog sound and intuitive control, the Subsequent 37 is a powerful tool for sound design and performance.
Specification
Moog Subsequent 37 Analog Synthesizer Details |
|
---|---|
Sound Engine | 100% Analog |
Polyphony | Selectable Monophonic or Paraphonic (2-Note) |
Keybed | 37-Note Semi-Weighted with After Pressure |
LCD | 128 x 64 Pixel LCD with White Backlight |
Controllers | Pitch Bend, Mod Wheel, After Pressure, Velocity |
Sound Sources | Two Variable Waveshape Oscillators, one Square Wave Sub Oscillator, one Analog Noise Generator, one External Input/Filter Feedback |
Oscillator Range | 22Hz–6.8KkHz |
Note Range at 8′ | 18–116 |
GLIDE MODULE | Assign to Osc1/Osc2/Both. Type – LCR, LCT, EXP, Gated, Legato |
FILTER | 20Hz–20kHz Moog Ladder Filter with 6/12/18/24dB/Oct Filter Slopes and MultiDrive |
Transposition | +/- 2 Octaves |
Arpeggiator/Sequencer | Up, Down, Order, Random, Latching, Back/Forth, Invert, +/-2 Range, Tie, Rest, MIDI Sync, 64-Note Sequencer |
Modulation Busses | Sources: LFO (Triangle, Square, Saw, Ramp, Sample & Hold), Filter EG/PGM Programmable Sources: Amp Env, Constant ON, Sine LFO, Noise LFO, Osc 1 Pitch, Osc 2 Pitch, Seq Note, Seq Vel, and Seq Mod DESTINATIONS: Osc 1 Pitch, Osc 2, Osc 1 & 2 Pitch, Filter, LFO Rate, VCA Level, Osc 1 Wave, Osc 2 Wave, Osc 1 & 2 Wave, Noise Level, EG Time/PGM |
LFO Panel | Hi/Low Range from .01Hz–1kHz, MIDI Sync, KB Reset |
ENVELOPES | DAHDSR Envelopes with Multi-Trigger, Reset, Looping, MIDI Sync, Latch and Variable control of EG Delay, Hold, Velocity Amount, KB Tracking |
Audio Input | 1xTS |
Audio Output | 1xTS, 1xTRS Headphone with Separate Volume Control |
Presets | 256 Presets, 16 Banks x 16 presets |
MIDI I/O | DIN In/Out and MIDI over USB |
CV/GATE Input | Filter CV, Pitch CV, Volume CV, KB Gate |
GATE Destinations | KB Gate (is also sequence gate), Ext. Gate, Arp/Seq Clock, Arp/Seq Run/Stop, Arp/Seq Step 1 Trig, Filt EG Trigger, Amp EG Trigger, LFO 1 Rate, LFO 2 Rate |
Dimensions | 6.75″ x 26.75″ x 14.75″ |
Weight | 22 lb. |
ข้อมูล
Moog Subsequent 37 Analog Synthesizer: พัฒนาไปอีกขั้นแห่งซินธ์อนาล็อก
Subsequent 37 เป็นซินธิไซเซอร์อนาล็อกแบบ (2-โน้ต) พาราโฟนิก ที่สร้างขึ้นจากดีไซน์อันได้รับรางวัลของ Sub 37 Tribute Edition แผงควบคุมมี 40 ปุ่มหมุนและ 74 สวิตช์ ช่วยให้คุณเข้าถึงเครื่องมือออกแบบเสียงอนาล็อกและตัวเลือกซีเควนซิ่งมากมายได้ทันที Subsequent 37 ปรับปรุงจากรุ่นก่อนหน้าผ่านการนำเสนอการปรับปรุงที่ผู้ใช้ร้องขอ แต่ละการปรับปรุงยังคงรักษาความมหัศจรรย์และเอกลักษณ์ของรุ่นก่อนไว้ พร้อมทั้งมอบมิติใหม่ของเสียงและการเล่นที่ดียิ่งขึ้น

คุณสมบัติเด่น
- ดีกว่าเดิม: ส่วนมิกเซอร์มีเฮดรูมเพิ่มขึ้นเป็นสองเท่า ให้โทนเสียงคลีนแบบคลาสสิกที่หลากหลายยิ่งขึ้นทั้งในโหมดโมโนและดูโอ
- เสียงอนาล็อกที่ได้รับการปรับปรุง: Ladder Filter ได้รับการปรับปรุงเพื่อเพิ่มความอิ่มตัวของฮาร์โมนิกและการบีบอัดแบบอนาล็อก ทำให้ได้เสียงต่ำที่หนักแน่นยิ่งขึ้น และ Multidrive circuit ที่ได้รับการปรับแต่งใหม่ให้เสียงแตกที่หลากหลายและดุดันกว่าเดิม
- ทรงพลังในการสร้างสรรค์เสียง: มาพร้อมพรีเซ็ต 256 แบบ, ออสซิลเลเตอร์สองตัวพร้อมรูปคลื่นที่ปรับเปลี่ยนได้, Sub Oscillator คลื่นสี่เหลี่ยมหนึ่งตัว, Analog Noise Generator หนึ่งตัว, External Input/Feedback Generator และ Moog Ladder Filter พร้อมความชันหลายระดับ
- การควบคุมที่ยืดหยุ่น: มี Mod Busses สองชุดที่กำหนดได้, DAHDSR Looping Envelopes สองชุด, Arpeggiator/Sequencer ที่ทรงพลัง และส่วนมิกเซอร์ที่ครบครันพร้อมปุ่มควบคุมและ Mute สำหรับแต่ละแหล่งเสียง
- ประสบการณ์การเล่นที่ยอดเยี่ยม: คีย์เบด semi-weighted 37 โน้ต ไวต่อความเร็วและ Aftertouch
สรุป
Moog Subsequent 37 Analog Synthesizer เป็นซินธิไซเซอร์อนาล็อกที่ทรงพลังและได้รับการปรับปรุงให้ดียิ่งขึ้น มอบเสียง Moog อันเป็นเอกลักษณ์ พร้อมความสามารถในการสร้างสรรค์เสียงที่หลากหลายและการควบคุมที่ยืดหยุ่น เหมาะสำหรับนักดนตรีและผู้ที่ชื่นชอบเสียงอนาล็อกอย่างแท้จริง
สเปค
รายละเอียด Moog Subsequent 37 Analog Synthesizer |
|
---|---|
Sound Engine | อนาล็อก 100% |
โพลีโฟนี | เลือกได้ระหว่างโมโนโฟนิกหรือพาราโฟนิก (2-โน้ต) |
คีย์เบด | 37 โน้ต Semi-Weighted พร้อม After Pressure |
LCD | 128 x 64 พิกเซล พร้อมไฟพื้นหลังสีขาว |
ตัวควบคุม | Pitch Bend, Mod Wheel, After Pressure, Velocity |
แหล่งกำเนิดเสียง | ออสซิลเลเตอร์สองตัวพร้อมรูปคลื่นที่ปรับเปลี่ยนได้, Sub Oscillator คลื่นสี่เหลี่ยมหนึ่งตัว, Analog Noise Generator หนึ่งตัว, External Input/Filter Feedback |
ช่วงออสซิลเลเตอร์ | 22Hz–6.8KkHz |
ช่วงโน้ตที่ 8′ | 18–116 |
Glide Module | กำหนดได้ที่ Osc1/Osc2/Both (LCR, LCT, EXP, Gated, Legato) |
Filter | 20Hz–20kHz Moog Ladder Filter พร้อมความชัน 6/12/18/24dB/Oct และ MultiDrive |
Transposition | +/- 2 ออคเทฟ |
Arpeggiator/Sequencer | Up, Down, Order, Random, Latching, Back/Forth, Invert, +/-2 Range, Tie, Rest, MIDI Sync, 64-Note Sequencer |
Modulation Busses | แหล่งที่มา: LFO (Triangle, Square, Saw, Ramp, Sample & Hold), Filter EG/PGM; ปลายทางที่ตั้งโปรแกรมได้: Amp Env, Constant ON, Sine LFO, Noise LFO, Osc 1 Pitch, Osc 2 Pitch, Seq Note, Seq Vel, และ Seq Mod; ปลายทาง: Osc 1 Pitch, Osc 2, Osc 1 & 2 Pitch, Filter, LFO Rate, VCA Level, Osc 1 Wave, Osc 2 Wave, Osc 1 & 2 Wave, Noise Level, EG Time/PGM |
LFO Panel | ช่วง Hi/Low จาก .01Hz–1kHz, MIDI Sync, KB Reset |
Envelopes | DAHDSR Envelopes พร้อม Multi-Trigger, Reset, Looping, MIDI Sync, Latch และการควบคุม EG Delay, Hold, Velocity Amount, KB Tracking ที่หลากหลาย |
Audio Input | 1xTS |
Audio Output | 1xTS, 1xTRS Headphone พร้อมปุ่มปรับระดับเสียงแยก |
Presets | 256 Presets (16 Banks x 16 Presets) |
MIDI I/O | DIN In/Out และ MIDI over USB |
CV/GATE Input | Filter CV, Pitch CV, Volume CV, KB Gate |
GATE Destinations | KB Gate (เป็น Sequence Gate ด้วย), Ext. Gate, Arp/Seq Clock, Arp/Seq Run/Stop, Arp/Seq Step 1 Trig, Filt EG Trigger, Amp EG Trigger, LFO 1 Rate, LFO 2 Rate |
ขนาด | 6.75″ x 26.75″ x 14.75″ |
น้ำหนัก | 22 ปอนด์ |
