Pirate Midi CLICK V2 MIDI to Analog, Wireless Midi Interface USB Host

UNMATCHED CONTROL OPTIONS

Take full control of your gear with multiple input methods:

• 3.5mm TRS MIDI cable
• USB MIDI (Host and Device ports)
• A passive Aux Switch (no MIDI required!)
• BLE MIDI
• Wi-Fi RTP MIDI

MIDI-TO-EXPRESSION CONVERSION

Transform your non-MIDI pedals with expression inputs into MIDI-responsive devices. Simply send MIDI Control Change data to the CLiCK v2, and it converts it into an analog expression signal for seamless integration with your pedalboard.

DUAL RELAY FUNCTIONALITY

Control your amp channels, aux jacks, tap tempo jacks, and other footswitch jacks using the two switching relays.

The relays can independently or simultaneously control:

• Tip
• Ring
• Tip+Ring

Whether you’re toggling individual relays or sending on/off commands, the CLiCK v2 works flawlessly with MIDI controllers, DAWs, mobile apps, web apps, or any device capable of sending MIDI signals.

Need to control two TS switchable devices instead of one TRS device? A Split-Y TRS to dual-TS cable (available at most music stores or online) will do the trick.

WIRELESS USB MIDI & INTERFACE

With Bluetooth Low Energy (BLE) and Wi-Fi onboard, you can now control your analog gear remotely with MIDI! Use an app, a controller, or cues in your backing tracks (DAW MIDI Automation) to trigger amp channel changes, expression sweeps, and more!

The CLiCK v2 also serves as a rugged, ultra-compact 3-in/3-out USB MIDI interface, making it one of the smallest and most reliable options available.

READY TO GO

The CLiCK v2 comes equipped with everything you need to get started:

1m USB Type-C cable included.

Optional 3.5mm TRS to 1/4” TRS or DIN5 adapters available from our web store.

Power it with USB or 9V DC

• MIDI In/Out: 3.5mm TRS jacks (MIDI Type A, MIDI Org Standard)
• Bluetooth Low Energy (BLE) MIDI In and Out
• Wi-Fi RTP MIDI In and Out
• USB Host Port
• USB Device Port
• Dimensions: 74mm x 44mm x 26mm
• Current Draw: 150mA
• Weight: 110 grams

• MIDI In/Out: ช่องเสียบ TRS ขนาด 3.5 มม. (MIDI Type A, มาตรฐาน MIDI Org)
• Bluetooth Low Energy (BLE) MIDI In and Out: MIDI เข้าและออกผ่าน Bluetooth Low Energy
• Wi-Fi RTP MIDI In and Out: MIDI เข้าและออกผ่าน Wi-Fi RTP
• USB Host Port: พอร์ต USB โฮสต์
• USB Device Port: พอร์ต USB ดีไวซ์
• ขนาด: 74 มม. x 44 มม. x 26 มม.
• อัตราการใช้กระแสไฟ: 150mA
• น้ำหนัก: 110 กรัม
