Solid State Logic SSL XL Desk Load with 16 EQ Module

คลิ๊กที่ภาพเพื่อขยาย
ยี่ห้อ : Solid State Logic
รุ่น :  Solid State Logic SSL XL Desk Load with 16 EQ Module Control Surfaces
การจัดส่ง : ซื้อครบ 500 บาท จัดส่งฟรีทั่วประเทศ / จัดส่งด่วนภายในวัน ทั่วกทม. และปริมณฑล

ราคา : 1,100,000 บาท

การชำระเงิน : ผ่อนไม่ใช้บัตรเครดิต / จ่ายหน้าร้าน 6สาขา / โอนเงิน / เก็บปลายทาง / บัตรเครดิต /ผ่อนชำระ 0% (บางรายการ) / Shopee / Lazada

สั่งซื้อ Solid State Logic SSL XL Desk Load with 16 EQ Moduleผ่านline สั่งซื้อ Solid State Logic SSL XL Desk Load with 16 EQ Moduleผ่าน messenger

วีดีโอ


YouTube video

Description

Solid State Logic SSL XL Desk Load with 16 EQ Module

XL-Desk is designed for tracking or mixing engineers who require an analogue console within a DAW centric studio, but don’t want or need the integrated DAW control and analogue level automation other SSL console products have made the new hybrid studio standard.

  • 8 SSL preamps deliver 75dB of pristine gain
  • Switchable Variable Harmonic Drive on every pre
  • Blend between tube and transistor distortion styles
  • Phantom power and -20dB pad on every preamp
  • Trim knob and hi-Z switch accommodate most levels
  • Same DC-coupled circuit design found in SSL’s top gear
  • Transparent signal path exceeds 24-bit/192kHz resolution
  • Extremely wide frequency range with flat response
  • Ultra-low distortion performance won’t color your sound
  • Virtually non-existent noise floor offers extended dynamics
  • Integrated 500 Series slots on all 16 mono channels
  • Mix Bus A includes SSL G Comp bus compressor
  • Slots 9–16 can be assigned to any stereo mix bus
  • Slots 1–16 are also accessible via DB-25 connectors
  • 4 mix buses provide legendary SSL summing
  • Insert points and direct outputs offer additional routing
  • ALT inputs on first 16 channels provide playback summing
  • Stereo Cue and both Aux sends can be pre or post fader
  • Uniform DB-25 I/O makes it easy to add a patchbay
  • Effortlessly switch between 3 sets of monitors
  • Assign a subwoofer in or out with each monitor set
  • Mono fold down, dim, and 2 solo modes onboard
  • Talkback mic feeds 2 of 3 headphone mixes
  • Recordable Listen Mic input with classic compression

Specification

Specification

  • Type: Analog
  • Channels: 24
  • Faders:  21 x 100mm
  • Inputs – Mic Preamps: 1 x DB25
  • Phantom Power: 8
  • Inputs – Line: 1 x DB25
  • Inputs – Other: 2 x DB25 (500), 2 x DB25 (Misc), 1 x DB25 (Mix)
  • Outputs – Main:  2 x XLR
  • Outputs – Direct:  2 x DB25
  • Outputs – Other:  2 x DB25 (500), 2 x DB25 (Misc), 1 x DB25 (Mix)
  • Headphones: 1 x 1/4″
  • Aux Sends: 1 x Stereo, 2 x Mono
  • Send/Return I/O: 1 x DB25 (Mix Send), 2 x DB25 (Insert Return), 2 x DB25 (Insert Send), 2 x DB25 (500 Return), 2 x DB25 (500 Send)
  • Busses/Groups: 4 x Bus (Stereo Mix)
  • Channel Inserts: Yes
  • USB: 1 x Type B (diagnostic only)
  • Talkback:  Yes
  • Effects: Yes (Compression)
  • Height: 9.9″
  • Width: 40″
  • Depth:  32″
  • Weight: 89.5 lbs.



×
