Behringer BM-15M เอฟเฟคกีตาร์

ราคา : (กรุณาสอบถาม)
ลูกค้าองค์กร/ใบเสนอราคา
E-mail: musicarmsproject@gmail.com


วีดีโอ

Description
Behringer BM-15M MURF BOX: Effects Pedal for Guitars and Synths
Based on one of the most unique and creative pedals of the early 2000s, the Behringer BM-15M MURF BOX combines 8 resonant filters across bass and middle frequency bands with a selection of interesting patterns, LFO modulation as well as versatile Envelope control to recreate the unmistakable rhythmic, sweeping effects found in the long-unavailable and highly valued original.
Key Features
- Analogue Circuitry: Authentic recreation featuring analogue circuitry for a truly vintage voiced sound.
- Classic Aesthetics: Roadworthy solid metal enclosure with wooden side panels.
- Go Further: Connect via USB to the Guitar Tribe App to customise patterns and presets.
- Even Further!: Versatile I/O and MIDI control allows for sound design manipulation via external CV or expression pedal.
- Filter: 8 resonant filters across bass and middle frequency bands.
- LFO Modulation and Envelope Control: Recreate rhythmic, sweeping effects.
- Designed for: Guitars and Synths.
Conclusion
The Behringer BM-15M MURF BOX is a unique and creative effects pedal reminiscent of a customisable rhythmic tremolo combined with a phaser and envelope filter. Designed for both guitars and synths with versatile control options, the MURF BOX is built to inspire your sound design.
Specification
Behringer BM-15M MURF BOX Specifications |
|
---|---|
Audio in | 1 x 1/4″ TS, unbalanced, 238 kΩ |
Left / mono out | 1 x 1/4″ TS, unbalanced, 1 kΩ |
Right out | 1 x 1/4″ TS, unbalanced, 1 kΩ |
Tap / step | 1 x 1/4″ TRS, balanced, 48 kΩ |
Rate | 1 x 1/4″ TRS, 22 kΩ, unbalanced, CV input range: 0 V to +5 V |
Mix | 1 x 1/4″ TRS, 22 kΩ, unbalanced, CV input range: 0 V to +5 V |
Envelope | 1 x 1/4″ TRS, 22 kΩ, unbalanced, CV input range: 0 V to +5 V |
LFO / sweep | 1 x 1/4″ TRS, 22 kΩ, unbalanced, CV input range: 0 V to +5 V |
MIDI in | 2 x 5-pin DIN, 16 channels |
USB | 1 x USB, type C |
Frequency response | 20 Hz to 20 kHz (+0 / -2 dB) |
Dynamic range | > 66 dB |
Signal-to-noise ratio | > 56 dB |
Overall gain | +16.5 dB |
Power input | Standard 9 V DC, centre negative, > 400 mA (power supply not included) |
Power consumption | 1.8 W |
Dimensions (H x W x D) | 85.9 x 147.6 x 196.9 mm (3.38 x 5.81 x 7.75″) |
Weight | 1,108 g (39.1 oz) |
ข้อมูล
Behringer BM-15M MURF BOX: เอฟเฟกต์กีตาร์และซินธิไซเซอร์
Behringer BM-15M MURF BOX ได้รับแรงบันดาลใจจากหนึ่งในเอฟเฟกต์เหยียบที่โดดเด่นและสร้างสรรค์ที่สุดในช่วงต้นทศวรรษ 2000 โดยเป็นการรวมเอา Resonant Filter 8 แบนด์ ครอบคลุมย่านความถี่เบสและกลาง พร้อมด้วย Pattern ที่น่าสนใจ การ Modulate ด้วย LFO และการควบคุม Envelope ที่หลากหลาย เพื่อสร้างเอฟเฟกต์ Rhythmic และ Sweeping อันเป็นเอกลักษณ์ของต้นฉบับที่หายากและมีมูลค่าสูง
คุณสมบัติเด่น
- วงจร Analog: สร้างเสียงแบบวินเทจอย่างแท้จริง
- ดีไซน์ Classic: ตัวเครื่องโลหะแข็งแรงทนทาน พร้อมแผงด้านข้างไม้
- เชื่อมต่อ USB: เพื่อขยายการใช้งานผ่าน Guitar Tribe App ปรับแต่ง Pattern และสร้าง Preset
- I/O และ MIDI ที่หลากหลาย: ควบคุม Parameter ผ่าน CV ภายนอก เช่น Behringer Neutron หรือ Expression Pedal
- Filter 8 แบนด์: Resonant Filter สำหรับย่านความถี่เบสและกลาง
- LFO Modulation และ Envelope Control: สร้างเอฟเฟกต์ Sweeping ที่เป็นเอกลักษณ์
- ทำงานได้กับกีตาร์และซินธิไซเซอร์:
บทสรุป
Behringer BM-15M MURF BOX เป็นเอฟเฟกต์ที่สร้างสรรค์และโดดเด่น เหมาะสำหรับผู้ที่ต้องการสร้างสรรค์เสียง Rhythmic ที่เป็นเอกลักษณ์คล้าย Tremolo, Phaser และ Envelope Filter พร้อมการควบคุมที่ยืดหยุ่นและเชื่อมต่อได้หลากหลาย
สเปค
รายละเอียด Behringer BM-15M MURF BOX |
|
---|---|
Audio in | 1 x 1/4″ TS, unbalanced, 238 kΩ |
Left / mono out | 1 x 1/4″ TS, unbalanced, 1 kΩ |
Right out | 1 x 1/4″ TS, unbalanced, 1 kΩ |
Tap / step | 1 x 1/4″ TRS, balanced, 48 kΩ |
Rate | 1 x 1/4″ TRS, 22 kΩ, unbalanced, CV input range: 0 V to +5 V |
Mix | 1 x 1/4″ TRS, 22 kΩ, unbalanced, CV input range: 0 V to +5 V |
Envelope | 1 x 1/4″ TRS, 22 kΩ, unbalanced, CV input range: 0 V to +5 V |
LFO / sweep | 1 x 1/4″ TRS, 22 kΩ, unbalanced, CV input range: 0 V to +5 V |
MIDI in | 2 x 5-pin DIN, 16 channels |
USB | 1 x USB, type C |
Frequency response | 20 Hz to 20 kHz (+0 / -2 dB) |
Dynamic range | > 66 dB |
Signal-to-noise ratio | > 56 dB |
Overall gain | +16.5 dB |
Power input | Standard 9 V DC, centre negative, > 400 mA (power supply not included) |
Power consumption | 1.8 W |
Dimensions (H x W x D) | 85.9 x 147.6 x 196.9 mm |
Weight | 1,108 g |
