Jim Dunlop MXR EVH Modern High Gain เอฟเฟคกีตาร์

คลิ๊กที่ภาพเพื่อขยาย
ยี่ห้อ : Jim Dunlop

ราคา : 12,000 บาท

รุ่น :  Jim Dunlop MXR EVH Modern High Gain เอฟเฟคก้อน Strombox
🚚 การจัดส่ง

ซื้อครบ 500 บาท จัดส่งฟรีทั่วประเทศ

🚀 จัดส่งด่วนภายในวัน ทั่วกทม. และปริมณฑล

💳 ช่องทางการชำระเงิน
จ่ายหน้าร้าน 13 สาขา โอนเงิน เก็บปลายทาง บัตรเครดิต ผ่อน 0% (บางรายการ) Shopee Lazada

🏢
ลูกค้าองค์กร / ขอใบเสนอราคา
สั่งซื้อ Jim Dunlop MXR EVH Modern High Gain เอฟเฟคกีตาร์ผ่านline สั่งซื้อ Jim Dunlop MXR EVH Modern High Gain เอฟเฟคกีตาร์ผ่าน messenger

วีดีโอ


Description

Jim Dunlop MXR EVH Modern High Gain: Saturated Distortion with Intact Clarity and Definition

The Jim Dunlop MXR EVH Modern High Gain pedal is voiced to deliver saturated, aggressive distortion with its core clarity and definition completely intact. Developed in close collaboration with Eddie Van Halen, this high-performance pedal focuses on a tight low end, strong midrange presence, and controlled high frequencies that cut through dense mixes effortlessly. Even at maximum gain settings, individual notes remain highly articulate, making the pedal perfectly suited for fast riffing, heavy rhythm work, and sustained lead playing without losing note separation or becoming muddy.

Key Features

  • Modern EVH High-Gain Voicing: Engineered with Eddie Van Halen to offer aggressive, saturated modern distortion while keeping note separation and articulation crisp, even at maximum gain.
  • Detailed EQ & Low-Frequency Control: Features a precise 3-band EQ section paired with a 55 Hz and 80 Hz voicing switch, allowing you to reshape the low end from a thicker, heavier feel to a tighter, punchier definition.
  • Integrated Boost Switch: Instantly increases gain and saturation for heavier passages or soaring solos without altering your core tone, facilitating seamless transitions between rhythm and lead settings.
  • Built-in Noise Gate for Controlled Performance: Includes a dedicated, adjustable noise gate to eliminate unwanted noise and feedback, keeping your high-gain signal tight while fully preserving sustain and dynamics.

The Ultimate High-Gain Tool for Modern Guitarists

High-gain tones demand absolute control and discipline, and the Jim Dunlop MXR EVH Modern High Gain delivers exactly that. Combining comprehensive tone shaping, an independent boost, and a built-in noise gate, this pedal provides a wide range of modern distortion textures from articulate crunch to fully saturated high-gain chaos. Elevate your pedalboard and experience uncompromised high-gain performance today.

Specification

MXR by Jim Dunlop EVHMHG Specifications

Brand MXR by Jim Dunlop
Model EVHMHG
Effect Type High Gain Distortion / Preamp Pedal
Bypass System True Hardwire Bypass
Equalizer (EQ) 3-Band EQ (Bass / Mid / Treble)
EQ Control Range • Bass: ±7 dB @ 30 Hz
• Mid: ±5 dB @ 700 Hz
• Treble: ±6 dB @ 10 kHz
Additional Functions Boost Switch, Noise Gate, 55Hz/80Hz Shift
Boost Gain +3 dB
Noise Floor • Gate Open: -76 dBV
• Gate Closed: -93 dBV
Input Impedance 740 kΩ
Output Impedance 1 kΩ
Nominal Output Level -22 dBV
Maximum Output Level 0 dBV
Current Draw • Normal: 15 mA
• Gate Active: 16.5 mA
• Boost Active: 20.5 mA
Power Supply 9V DC (Standard Center Negative AC adapter)
Finish / Color EVH Signature Red
Enclosure Type & Material Compact MXR Enclosure, High-strength Heavy-duty Die-Cast Metal
Best Suited For Hard Rock, Heavy Metal, Modern Metal, Progressive Metal
Dimensions (W x D x H) 95 mm x 120 mm x 55 mm
Weight Approx. 340 g

ข้อมูลสินค้า

Jim Dunlop MXR EVH Modern High Gain: นิยามใหม่ของเสียงแตกทรงพลัง ดุดัน คมชัดในสไตล์ Modern High-Gain

Jim Dunlop MXR EVH Modern High Gain คือเอฟเฟกต์ก้อนเสียงแตกที่ได้รับการพัฒนาขึ้นร่วมกับมือกีตาร์ระดับตำนานอย่าง Eddie Van Halen เพื่อมอบซาวด์แบบ Modern EVH High-Gain ที่ให้เสียงแตกอิ่มตัว (Saturated Distortion) ทรงพลัง ดุดัน แต่ยังคงไว้ซึ่งความคมชัดและมิติของตัวโน้ตอย่างครบถ้วน ตัวเพดัลโดดเด่นด้วยการตอบสนองย่านเบสที่กระชับ ย่านเสียงกลางที่พุ่งชัด และย่านแหลมที่ถูกควบคุมมาอย่างดีเยี่ยมเพื่อการรวบรวมไดนามิกให้พุ่งทะลุมิกซ์ แม้จะเปิด Gain ไว้ในระดับสูงสุด แต่การแยกแยะโน้ตแต่ละสายยังคงชัดเจน ไม่พร่ามัว เหมาะอย่างยิ่งสำหรับท่อนริฟฟ์ที่รวดเร็ว งานริธึมที่หนักหน่วง และการโซโล่ที่ต้องการซัสเทนยาวนาน

คุณสมบัติเด่น

  • Modern EVH High-Gain Voicing: โทนเสียงแตกที่ออกแบบร่วมกับ Eddie Van Halen ให้เสียงดุดัน ทรงพลัง แต่อาร์ติคูเลชัน (Articulation) ชัดเจน โน้ตไม่เบลอแม้เปิด Gain สูงสุด
  • Detailed 3-Band EQ & Low-Frequency Voicing Switch: ปรับแต่งโทนเสียงได้อย่างละเอียดด้วยปุ่ม EQ 3 ย่าน (Bass, Mid, Treble) พร้อมสวิตช์เลือกย่านความถี่ต่ำ 55 Hz และ 80 Hz เพื่อปรับเปลี่ยนคาแรคเตอร์ย่านเบสให้หนาแน่นสะใจหรือกระชับกระแทกกระทั้น
  • Integrated Boost Function & Gain Structure: สวิตช์ Boost ในตัว ช่วยเพิ่มระดับ Gain และความอิ่มตัวของสัญญาณสำหรับท่อนสลับหรือการโซโล่ โดยไม่ทำให้โทนเสียงหลักเพี้ยนไป ช่วยให้เปลี่ยนจากริธึมเป็นลีดได้อย่างราบรื่น
  • Built-in Dedicated Noise Gate: วงจรตัดเสียงรบกวนในตัวที่ปรับระดับได้ ช่วยควบคุมเสียงจี่และเสียงหอน (Feedback) ได้อย่างเบ็ดเสร็จ รักษาความกระชับของสัญญาณ โดยไม่ทำลายไดนามิกและหางเสียงซัสเทน

เติมเต็มจิตวิญญาณร็อคสมัยใหม่ในแบบ EVH

หากคุณกำลังมองหาเอฟเฟกต์เสียงแตกที่ตอบโจทย์แนวดนตรีร็อคและเมทัลสมัยใหม่ที่ต้องการทั้งความสะใจและความสะอาดคมชัด Jim Dunlop MXR EVH Modern High Gain คือคำตอบที่ดีที่สุด ด้วยสเปกที่อัดแน่นทั้ง EQ แบบละเอียด, ฟังก์ชัน Boost ในตัว และ Noise Gate ประสิทธิภาพสูง พร้อมแล้วที่จะเปลี่ยนแอมป์ของคุณให้กลายเป็นอสูรกายไฮเกน สัมผัสพลังเสียงระดับตำนานได้แล้ววันนี้

รายละเอียดคุณสมบัติ

MXR by Jim Dunlop EVHMHG Details

แบรนด์ / ผู้ผลิต MXR by Jim Dunlop
รุ่น EVHMHG
ประเภทเอฟเฟกต์ High Gain Distortion / Preamp Pedal
ระบบบายพาส True Hardwire Bypass
ระบบปรับแต่งโทนเสียง (EQ) 3-Band EQ (Bass / Mid / Treble)
การควบคุมย่านความถี่ (EQ Spec) • Bass: ±7 dB @ 30 Hz
• Mid: ±5 dB @ 700 Hz
• Treble: ±6 dB @ 10 kHz
ฟังก์ชันเสริมและสวิตช์ควบคุม Boost Switch, Noise Gate, 55Hz/80Hz Shift Switch
ระดับความแรงสลับบูสต์ (Boost Gain) +3 dB
ระดับสัญญาณรบกวน (Noise Floor) • เมื่อเปิดเกต (Gate Open): -76 dBV
• เมื่อปิดเกต (Gate Closed): -93 dBV
อินพุตอิมพีแดนซ์ (Input Impedance) 740 kΩ
เอาต์พุตอิมพีแดนซ์ (Output Impedance) 1 kΩ
ระดับเอาต์พุตปกติ (Nominal Output) -22 dBV
ระดับเอาต์พุตสูงสุด (Maximum Output) 0 dBV
การกินกระแสไฟ (Current Draw) • สถานะปกติ: 15 mA
• เมื่อเปิด Noise Gate: 16.5 mA
• เมื่อเปิดฟังก์ชัน Boost: 20.5 mA
ระบบจ่ายไฟ DC 9V (รองรับอะแดปเตอร์มาตรฐานแบบ Center Negative / แกนในลบ)
สี / ดีไซน์ตัวเครื่อง สีแดงแดงลายซิกเนเจอร์ (แดง EVH Signature)
วัสดุและรูปแบบตัวถัง โลหะหล่อขึ้นรูป Die-Cast แข็งแรงทนทานสูง โครงสร้างแบบ Compact MXR Enclosure
แนวเพลงที่เหมาะสม Hard Rock, Heavy Metal, Modern Metal, Progressive Metal
ขนาด (ความกว้าง x ความลึก x ความสูง) 95 มม. x 120 มม. x 55 มม.
น้ำหนัก ประมาณ 340 กรัม
