Warm Audio WA-251 ไมค์คอนเดนเซอร์

A sound heard on countless iconic recordings

Their acclaimed vintage-inspired compressors, preamps, and mics have famously upset the pro audio price/performance ratio, so when Warm Audio turned its attention to the godfather of large-diaphragm tube condenser microphones, you know it had to be good. And is it ever! With its discrete, transformer-balanced vacuum tube circuitry and custom reproduction capsule, the Warm Audio WA-251 nails the huge, creamy sound of the beloved and revered ’251 — a sound heard on countless iconic recordings.

No source the WA-251 can’t finesse

Flash back to any top recording studio in the 1960s, and you’d see the venerable ’251 everywhere. Now it occupies a lofty perch in the pantheon of the greatest microphones ever made. It’s this classic circuit design — dating back more than a half century — that Warm Audio closely followed for the WA-251. This faithful replica uses a custom all-brass true CK-12-style capsule. Three polar patterns and robust 132dB SPL handling translate to incredible versatility; there’s literally no source the WA-251 can’t finesse with its inimitable, seductive sonics. Engineers at Sweetwater who have worked with the iconic original are beyond impressed. And you will be too.

Explore the sonic possibilities

The WA-251’s three polar patterns — cardioid, omnidirectional, and figure-8 — give you immense flexibility when it comes to exploring the sonic possibilities offered by different recording techniques. With two of these superb microphones, you can implement stereo techniques such as spaced pair (A/B), XY (including Blumlein), ORTF array, and mid-side (M-S). For full orchestra, add a third WA-251 for the minimalist — and highly effective — Mercury Living Presence technique: three spaced omnis across the orchestral soundstage, centered above the conductor’s podium. Set all three channels for unity gain, trim for the loudest musical peaks, and leave those faders alone. Let the conductor balance the orchestra (as nature intended).

A ’251 for the rest of us

What can you achieve with the WA-251? Every studio needs at least one pair of high-quality large-diaphragm condenser mics, and the Warm Audio WA-251 is designed after a legendary one. You can use the WA-251 on anything — with world-class results. It’s simply stunning on vocals, acoustic guitars, double bass, electric guitar and bass cabs, piano, drums and percussion, strings, brass, woodwinds, and any other source you’d care to throw at it. In fact, you could mic an entire symphony orchestra with nothing but three judiciously placed WA-251s set to omni. Considering its amazing value, it would be wise to get two for recording tracks in stereo. You haven’t lived until you’ve heard a grand piano spring to life when miked with a pair of ’251s. For drum room mics, use two WA-251s and nuke the stereo signal with a fast compressor. Positively explosive!

Features:

• Faithful replica of the classic ’251-style large-diaphragm condenser mic
• Custom all-brass CK-12-style capsule
• Custom CineMag USA transformer
• JJ Slovak 12AY7 vacuum tube
• Gotham 5-meter GAC-7 7-pin tube microphone cable
• WIMA, Solen French, and polystyrene capacitors
• 3 polar patterns: cardioid, omni, figure-8
• Dynamic range: 125dBA
• Maximum SPL: 132dB (<0.5% THD)
• Frequency range: 20Hz–20kHz
• Output impedance: 200 ohms
• Rated load impedance: ≥2k ohms
• S/N ratio: 80dBA
• Equivalent noise: 12dBA (IEC651)
• External IEC grounded PSU
• Includes 7-pin cable, wood box, power supply, and shockmount

Specs

• Microphone Type:Tube Condenser
• Mono/Stereo:Mono
• Polar Pattern:Cardioid, Omnidirectional, Figure-8
• Diaphragm Size:Large diaphragm
• Frequency Response:20Hz-20kHz
• Max SPL:132dB SPL
• Output Impedance:200 ohms
• Signal to Noise Ratio:80dB (A weighted)
• Self Noise:12dB (A weighted)
• Tube:JJ Slovak 12AY7
• Features:Custom CineMag USA transformer
• Power Source:External Power Supply
• Connector:7-pin (mic), XLR (power supply)
• Dimensions:9.72″ x 1.81″
• Included Accessories:Shockmount, Gotham Cable, Wood box

สเปกทางเทคนิค (Specifications)

ประเภทไมโครโฟน: ไมโครโฟนคอนเดนเซอร์แบบหลอดสุญญากาศ
การใช้งาน: โมโน
รูปแบบการรับเสียง: คาร์ดิออยด์, ออมนิไดเรกชันนัล, ฟิกเกอร์-8
ขนาดไดอะแฟรม: ไดอะแฟรมขนาดใหญ่
ช่วงความถี่ตอบสนอง: 20Hz–20kHz
ระดับเสียงสูงสุด (Max SPL): 132dB SPL
อิมพีแดนซ์ขาออก: 200 โอห์ม
อัตราสัญญาณต่อเสียงรบกวน (S/N Ratio): 80dB (A-weighted)
เสียงรบกวนตัวเอง (Self Noise): 12dB (A-weighted)
หลอดสุญญากาศภายใน: JJ Slovak รุ่น 12AY7
คุณสมบัติเสริม: ทรานส์ฟอร์เมอร์ CineMag USA แบบสั่งผลิตพิเศษ
แหล่งพลังงาน: เพาเวอร์ซัพพลายภายนอก
ขั้วต่อสัญญาณ: 7-pin (จากไมโครโฟน), XLR (จากเพาเวอร์ซัพพลาย)
ขนาดไมโครโฟน: 9.72 นิ้ว x 1.81 นิ้ว
อุปกรณ์ในชุด: โช้กเมาท์, สาย Gotham, กล่องไม้
