Zoom R4 Handheld MultiTrak 4-Track Mixer/Recorder เครื่องบันทึกเสียง

ราคา : 4,960 บาท
✅ ซื้อครบ 500 บาท จัดส่งฟรีทั่วประเทศ
🚀 จัดส่งด่วนภายในวัน ทั่วกทม. และปริมณฑล
วีดีโอ
Description
Zoom R4 Multitrack Recorder: Portable 4-Track Recording with 32-Bit Float Technology
The Zoom R4 Multitrack Recorder is a compact four-track audio recorder designed for musicians and creative songwriters. Its built-in omnidirectional microphone lets you capture musical ideas whenever inspiration strikes, while 32-bit float recording and dual AD circuitry help preserve audio detail and provide flexibility when managing recording levels. With onboard mixing tools, track-based effects, and versatile input options, the R4 is a convenient solution for recording vocals, instruments, and musical ideas wherever creativity takes you.
Key Features
- Four-Track Multitrack Recording: Record and manage up to four tracks, making it suitable for songwriting, demos, and music production.
- 32-Bit Float Recording: Captures detailed audio while providing greater flexibility when managing recording levels during post-production.
- Dual AD Circuitry: Designed to support detailed audio capture across a wide dynamic range.
- Built-In Omnidirectional Microphone: Capture ideas without connecting an external microphone. Ideal for recording vocals, guitars, pianos, and other sound sources.
- Two XLR/TRS Combo Inputs: Connect compatible microphones, instruments, keyboards, synthesizers, and other audio sources. Built-in 48V phantom power supports compatible condenser microphones.
- Onboard Effects and Sound Shaping: Each track provides audio-processing tools, including 3-band EQ, pan, echo, and reverb, for shaping your mix directly on the recorder.
- Intuitive Mixing Controls: Four faders, transport controls, and an LCD display make it easy to adjust levels, navigate tracks, and mix your recordings. An Undo function lets you reverse supported operations.
- 32-Bit Float Audio Interface: Connect the R4 to a compatible computer or smartphone via USB-C for use as an audio interface.
- Portable Power Options: Operates on four AA batteries (not included) or can be powered through its USB-C port.
Capture Your Musical Ideas Anywhere
The Zoom R4 Multitrack Recorder gives musicians a portable way to record ideas, develop song arrangements, and create demos without relying on a full studio setup. Combining four-track recording, 32-bit float technology, a built-in microphone, onboard effects, and USB-C connectivity, it is a versatile tool for both studio sessions and music creation on the go.
Specification
Zoom R4 Multitrack Recorder Details |
|
|---|---|
| Inputs | 1 Built-in Mic (Mono), 2 XLR/TS Inputs (Mono) |
| Outputs | 1 Headphone Output |
| XLR/TRS Input Connectors | 2 Balanced XLR/TRS Combo Jacks (XLR: Pin 2 Hot) |
| Input Gain | No adjustment required (Dual A/D Converter Circuit) |
| Input Impedance | XLR: 2.3 kΩ, TS: 1 MΩ |
| Maximum Input Level | XLR: +4 dBu, TS: +10 dBu |
| Phantom Power | +48 V (Individually switchable for INPUT A and INPUT B) |
| Equivalent Input Noise (EIN) | XLR: −120 dBu or less (IHF-A), TS: −107 dBu or less (IHF-A) |
| Input Frequency Response | XLR: −0.5 / +0.0 dB at 20 Hz–20 kHz TS: −0.2 / +0.0 dB at 20 Hz–20 kHz |
| Built-in Microphone | Omnidirectional, no input gain adjustment required (Dual A/D Converter Circuit), maximum input sound pressure level: 115 dB SPL |
| Headphone Connector | 1 Stereo 3.5 mm Mini Jack |
| Headphone Output Impedance | 10 Ω |
| Maximum Headphone Output Level | 20 mW + 20 mW (Into a 32 Ω Load) |
| Maximum Simultaneous Recording Tracks | 2 Tracks |
| Recording Format | WAV, 48 kHz, 32-bit Float, Mono |
| Recording Media | microSDHC-Compatible Cards: 4–32 GB; microSDXC-Compatible Cards: 64 GB–1 TB |
| Display | 2-inch Full-Color LCD, 240 × 320 Pixels |
| USB Connector | USB Type-C; USB bus power supported. Use a USB cable that supports data transfer. |
| Audio Interface Function | USB 2.0 High Speed, 48 kHz Sampling Frequency, 24-bit / 32-bit Float, 2 In / 2 Out |
| Mass Storage Function | USB 2.0 High Speed |
| Power Supply | 4 AA Batteries (Alkaline, Lithium, or Rechargeable NiMH) or ZOOM AD-17 AC Adapter (5 V / 1.0 A); USB bus power supported |
| Estimated Battery Life | Alkaline Batteries: Approx. 7 Hours NiMH Batteries (1900 mAh): Approx. 6 Hours Lithium Batteries: Approx. 14 Hours |
| Battery Life Test Conditions | Recording 1 track, playing 1 track, phantom power off, headphones connected to a 32 Ω load, and power-saving mode enabled. Figures are approximate, based on in-house testing, and may vary significantly depending on usage conditions. |
| Power Consumption | 5 W |
| Dimensions | 74 mm (W) × 138 mm (D) × 36 mm (H) |
| Weight (Including Batteries) | 287 g |
ข้อมูลสินค้า
Zoom R4 Multitrack Recorder: เครื่องบันทึกเสียง 4 แทร็ก พร้อมระบบบันทึก 32-Bit Float
Zoom R4 Multitrack Recorder เครื่องบันทึกเสียงแบบมัลติแทร็กขนาดกะทัดรัด ออกแบบมาสำหรับนักดนตรีและนักสร้างสรรค์เพลงโดยเฉพาะ มาพร้อมไมโครโฟน Omni-directional ในตัว ช่วยบันทึกไอเดียทางดนตรีได้ทันทีที่เกิดแรงบันดาลใจ พร้อมเทคโนโลยีบันทึกเสียงแบบ 32-Bit Float และวงจร Dual AD ที่ช่วยเก็บรายละเอียดเสียงได้อย่างแม่นยำ สามารถบันทึกเสียงร้อง เครื่องดนตรี และแหล่งกำเนิดเสียงต่าง ๆ พร้อมมิกซ์เสียงและใส่เอฟเฟกต์ได้ภายในเครื่อง เหมาะสำหรับการแต่งเพลงและสร้างเดโมได้ทุกที่
คุณสมบัติเด่น
- เครื่องบันทึกเสียง 4 แทร็ก: บันทึกและจัดการเสียงได้สูงสุด 4 แทร็ก เหมาะสำหรับการแต่งเพลง การทำเดโม และการสร้างสรรค์ผลงานเพลง
- ระบบบันทึกเสียง 32-Bit Float: ช่วยเก็บรายละเอียดเสียงและเพิ่มความยืดหยุ่นในการจัดการระดับเสียงระหว่างการบันทึกและขั้นตอนหลังการบันทึก
- วงจร Dual AD: ออกแบบมาเพื่อรองรับการบันทึกเสียงที่มีรายละเอียดและช่วงไดนามิกกว้าง
- ไมโครโฟน Omni-directional ในตัว: บันทึกเสียงได้สะดวกโดยไม่ต้องต่อไมโครโฟนภายนอก เหมาะสำหรับเก็บไอเดียเสียงร้อง กีตาร์ เปียโน และแหล่งเสียงอื่น ๆ
- อินพุต XLR/TRS Combo จำนวน 2 ช่อง: รองรับการเชื่อมต่อไมโครโฟน เครื่องดนตรี คีย์บอร์ด ซินธิไซเซอร์ และแหล่งสัญญาณเสียงที่เข้ากันได้ พร้อมไฟ Phantom Power 48V สำหรับไมโครโฟนคอนเดนเซอร์ที่รองรับ
- เอฟเฟกต์และการปรับแต่งเสียง: แต่ละแทร็กมีเครื่องมือปรับแต่งเสียง เช่น EQ 3 แบนด์, Pan, Echo และ Reverb ช่วยสร้างมิติและปรับสมดุลเสียงได้ภายในเครื่อง
- มิกซ์เสียงและจัดการแทร็กได้สะดวก: มีเฟดเดอร์ 4 ตัว ปุ่มควบคุมการเล่น และหน้าจอ LCD สำหรับปรับระดับเสียง จัดการแทร็ก และมิกซ์ผลงาน พร้อมฟังก์ชัน Undo สำหรับย้อนกลับการทำงานที่รองรับ
- รองรับการใช้งานเป็น Audio Interface: เชื่อมต่อกับคอมพิวเตอร์หรือสมาร์ตโฟนผ่าน USB-C เพื่อใช้งานเป็นออดิโออินเทอร์เฟซแบบ 32-Bit Float
- พกพาสะดวกและเลือกแหล่งจ่ายไฟได้: ใช้พลังงานจากแบตเตอรี่ AA จำนวน 4 ก้อน (ไม่รวมในชุด) หรือจ่ายไฟผ่านพอร์ต USB-C
สร้างสรรค์และบันทึกเพลงได้ทุกที่ด้วย Zoom R4
Zoom R4 Multitrack Recorder เป็นตัวช่วยสำหรับนักดนตรีที่ต้องการบันทึกไอเดีย แต่งเพลง และสร้างเดโมได้อย่างคล่องตัว ด้วยการบันทึกเสียง 4 แทร็ก ระบบ 32-Bit Float ไมโครโฟนในตัว เอฟเฟกต์สำหรับปรับแต่งเสียง และความสามารถในการเชื่อมต่อกับคอมพิวเตอร์หรือสมาร์ตโฟน จึงเหมาะสำหรับทั้งการใช้งานในสตูดิโอและการสร้างสรรค์ผลงานนอกสถานที่
รายละเอียดคุณสมบัติ
Zoom R4 Multitrack Recorder รายละเอียดสินค้า |
|
|---|---|
| อินพุต | ไมโครโฟนในตัว (โมโน) 1 ช่อง, อินพุต XLR/TS (โมโน) 2 ช่อง |
| เอาต์พุต | ช่องต่อหูฟัง 1 ช่อง |
| ขั้วต่ออินพุต XLR/TRS | ช่องต่อคอมโบ XLR/TRS แบบบาลานซ์ 2 ช่อง (XLR: ขา 2 เป็นสัญญาณบวก) |
| การปรับเกนอินพุต | ไม่จำเป็นต้องปรับ เนื่องจากใช้วงจร Dual A/D Converter |
| อิมพีแดนซ์อินพุต | XLR: 2.3 kΩ, TS: 1 MΩ |
| ระดับสัญญาณอินพุตสูงสุด | XLR: +4 dBu, TS: +10 dBu |
| ไฟ Phantom Power | +48 V (เลือกเปิด-ปิดแยกสำหรับ INPUT A และ INPUT B ได้) |
| สัญญาณรบกวนอินพุตเทียบเท่า (EIN) | XLR: −120 dBu หรือต่ำกว่า (IHF-A), TS: −107 dBu หรือต่ำกว่า (IHF-A) |
| การตอบสนองความถี่ของอินพุต | XLR: −0.5 / +0.0 dB ที่ 20 Hz–20 kHz TS: −0.2 / +0.0 dB ที่ 20 Hz–20 kHz |
| ไมโครโฟนในตัว | รับเสียงรอบทิศทาง (Omnidirectional), ไม่จำเป็นต้องปรับเกนด้วยวงจร Dual A/D Converter, รองรับระดับความดันเสียงสูงสุด 115 dB SPL |
| ช่องต่อหูฟัง | มินิแจ็คสเตอริโอ 3.5 มม. จำนวน 1 ช่อง |
| อิมพีแดนซ์เอาต์พุตหูฟัง | 10 Ω |
| กำลังเอาต์พุตหูฟังสูงสุด | 20 mW + 20 mW (เมื่อใช้โหลด 32 Ω) |
| จำนวนแทร็กที่บันทึกพร้อมกันสูงสุด | 2 แทร็ก |
| รูปแบบการบันทึก | WAV, 48 kHz, 32-bit Float, โมโน |
| สื่อบันทึกข้อมูล | การ์ด microSDHC ขนาด 4–32 GB และการ์ด microSDXC ขนาด 64 GB–1 TB |
| หน้าจอแสดงผล | LCD สี ขนาด 2 นิ้ว ความละเอียด 240 × 320 พิกเซล |
| พอร์ต USB | USB Type-C รองรับ USB Bus Power โดยใช้สาย USB ที่รองรับการถ่ายโอนข้อมูล |
| ฟังก์ชัน Audio Interface | USB 2.0 High Speed, Sampling Frequency 48 kHz, ความละเอียด 24-bit / 32-bit Float, อินพุต/เอาต์พุต 2 In / 2 Out |
| ฟังก์ชัน Mass Storage | USB 2.0 High Speed |
| แหล่งจ่ายไฟ | แบตเตอรี่ AA จำนวน 4 ก้อน (อัลคาไลน์ ลิเธียม หรือ NiMH แบบชาร์จได้) หรืออะแดปเตอร์ ZOOM AD-17 (5 V / 1.0 A) และรองรับการจ่ายไฟผ่าน USB |
| ระยะเวลาใช้งานโดยประมาณด้วยแบตเตอรี่ | อัลคาไลน์: ประมาณ 7 ชั่วโมง NiMH (1900 mAh): ประมาณ 6 ชั่วโมง ลิเธียม: ประมาณ 14 ชั่วโมง |
| เงื่อนไขการทดสอบแบตเตอรี่ | บันทึก 1 แทร็ก เล่นเสียง 1 แทร็ก ปิด Phantom Power ใช้หูฟังโหลด 32 Ω และเปิดโหมดประหยัดพลังงาน ระยะเวลาเป็นค่าโดยประมาณจากการทดสอบภายใน และอาจแตกต่างตามสภาพการใช้งาน |
| กำลังไฟฟ้าที่ใช้ | 5 W |
| ขนาด | กว้าง 74 × ลึก 138 × สูง 36 มม. |
| น้ำหนัก (รวมแบตเตอรี่) | 287 กรัม |
