ZOOMUAC2USB 3.0 Audio Interface
ราคา : 9,599 บาท
ลูกค้าองค์กร/ใบเสนอราคา
E-mail: musicarmsproject@gmail.com
Description
USB 3.0 SuperSpeed Audio Converter for Mac and PC
Take your sound new heights with the high-speed, high-resolution, low-latency, and ultra-portable UAC-2 SuperSpeed USB 3.0 Audio converter.
The bus-powered UAC-2 adds two channels of 24-bit/192 kHz high-resolution audio to any USB 2.0 or 3.0-equipped Windows or Mac computer—even to your iPad.* It utilizes SuperSpeed USB 3.0 technology for low latency and includes advanced features such as 4x upsampling, Loopback, and MIDI I/O. Plug in any microphone, line-level device, or instrument and use the UAC-2 for onstage playback, recording to a DAW, or enjoyment of high-res audio in your home or office. You can also use it for fast, low-latency podcasting, gaming, and other live streaming applications.
FEATURES AT A GLANCE
2-in/2-out SuperSpeed USB 3.0 audio interface
Support for recording and playback up to 24-bit/192 kHz
Loopback function for webcasting, podcasting, gaming, and other live streaming applications
Low latency overdubbing and direct monitoring for zero-latency monitoring in mono or stereo
Two combo balanced XLR/TRS input connectors accept both mic- and line-level signal
Hi-Z switches allow direct connection of electric guitar or bass
Switchable +48V phantom power
Two balanced TRS output jacks for connection to amplifiers or self-powered speakers
¼” headphone jack with dedicated level control
Independent gain controls and clip LEDs for each input
Large knob output volume control
Direct Monitoring switch for zero latency monitoring in mono or stereo
MIDI In and Out
Compatible with all popular DAW and streaming software, including Cubase, Logic, Garage Band, Pro Tools, Ableton Live, and others
High-performance mic preamps with up to +60dB of amplification
120dB of dynamic range
4x upsampling during A/D and D/A conversion for reduced noise and enhanced fidelity
Asynchronous transfer system unaffected by computer jitter
Bus powered—no AC power required
Robust metal housing ensures roadworthiness
Works with all USB 3.0-equipped computers and iPads
Specification
Specification
INPUTS
| INPUT 1/2 CONNECTORS: | XLR/TRS combo jacks (XLR: 2 hot / TRS: TIP hot) |
| INPUT GAIN: | 0 to 60dB in 1dB steps |
| INPUT IMPEDANCE: | 5kΩ (1 MΩ (when Hi-Z ON) |
| MAXIMUM INPUT LEVEL: | +12 dBu (@0dBFs) |
| PHANTOM POWER: | +48V |
L/R OUTPUT
| TYPE: | ¼” TRS jack (Balanced) |
| MAXIMUM OUTPUT LEVEL: | +14 dBu (@0dBFs) |
| OUTPUT IMPEDANCE: | 100Ω |
PHONES OUTPUT
| TYPE: | ¼” stereo phone jack 20mW + 20mW (into 32Ω load) |
| MAXIMUM OUTPUT LEVEL: | +8 dBu (@0dBFs) |
| OUTPUT IMPEDANCE: | 33Ω |
DYNAMIC RANGE
| A/D: | 118dB typical (IHF-A) |
| D/A: | 120dB typical (IHF-A) |
NUMBER OF AUDIO CHANNELS
| RECORDING: | 2 |
| PLAYBACK: | 2 |
OTHER
| FREQUENCY CHARACTERISTICS: | -1.0 dB: 20 Hz – 60 kHz @ 192kHz -1.0 dB: 20 Hz – 40 kHz @ 96kHz -1.0 dB: 20 Hz – 20 kHz @ 44.1kHz |
| MEASURED CONVERSION NOISE (EIN): | -125dBu (IHF-A) @ 60dB, 150Ω input |
| SAMPLING FREQUENCIES: | 192kHz, 176.4kHz, 96kHz, 88.2kHz, 48kHz, 44.1kHz |
| BIT DEPTH: | 24-bit |
| INTERFACE: | USB 3.0 |
| MIDI IN/OUT: | 5-pin DIN jack |
| POWER SOURCE: | USB 3.0 Bus Power / AD-14 AC adapter (DC 5V 1A) |
| POWER CONSUMPTION: | 5 W maximum |
| DIMENSIONS: | 113.9mm(D) x 176.0mm(W) x 46.2mm (H) |
| WEIGHT: | 750g |
UAC-2 SYSTEM REQUIREMENTS
| WINDOWS: | OS： Windows® 8 ~ 11 (32bit/64bit) CPU: Intel® Core i3 or faster* USB: USB 3.0/USB 2.0** * Operation is not guaranteed with CPUs from Atom, Celeron or Pentium series or CPUs made by AMD. ** Only USB host controllers with Intel Chipsets are supported. Operation is not guaranteed when used with USB hubs or expansion cards. |
| MAC: | OS： macOS 10.14 ~ 12 CPU: Intel® Core i3 or fasterUSB: USB 3.0/USB 2.0** Operation is not guaranteed when used with USB hubs or expansion cards. |
| IPHONE/IPAD: | OS: iOS 7.1 ~ 15 * Optional power adapter(AD-14) and Apple Camera Connection kit or Lightning to USB Camera Adapter required. |
